8 Channel 3-24V Relay Module Solid State High Level SSR DC Control DC with Resistive Fuse
Introducing the 8 Channel 3-24V Solid State Relay Module, a versatile solution for efficiently controlling high-voltage DC loads from lower voltage DC control circuitry. With solid-state technology, this module offers enhanced performance and longevity compared to traditional mechanical relays.
Features:
- 8-Channel Solid State Relay Board: Control up to 8 loads independently with ease.
- 2 AMP Capacity: Each channel can handle loads of up to 2 amps at 50 V DC, providing ample power for various applications.
- Wide Input Voltage Range: Compatible with input voltages ranging from 3V to 24V DC, offering flexibility in control circuitry design.
- Versatile Usage: Ideal for controlling lighting systems, holiday displays, and other appliances or equipment requiring high-current switching.
- Assembled and Tested: Each module has been fully assembled and electrically tested for reliable operation.
- LED Indicator: Features LED indicators for each relay, enabling quick status monitoring.
- Microcontroller Compatibility: Can be easily controlled directly by a microcontroller, simplifying integration into existing systems.
- Noise-Free Operation: Generates no noise during operation, ensuring smooth and quiet performance.
- Long Service Life: Solid-state design offers a longer lifespan compared to traditional mechanical relays.
Input Parts:
- DC: Connect to VCC to supply power according to relay voltage.
- DC-: Connect to GND for ground connection.
- IN1-IN8: Individual input signals for triggering each channel relay (active at the high level).
Upgrade your control system with the 8 Channel 3-24V Solid State Relay Module and experience enhanced reliability, flexibility, and performance in your projects. Whether you’re managing lighting systems, holiday displays, or other appliances, this module offers seamless control and peace of mind.
Specifications:
| Power supply | 3-24VDC/160mA |
|---|---|
| Trigger Voltage (VDC) | 3-24 V |
| Switching Voltage (VDC) | 50@2A |
| Isolation | Phototriac |
| Zero Cross | Yes |
| Shipping Weight | 0.1 kg |
| Shipping Dimensions | 8 × 6 × 3 cm |
Package Includes:
1 x 4 Channel 5V Relay Module Solid State High-Level SSR DC Control 250V 2A with Resistive Fuse
8 Channel 3-24V Relay Module Solid State High Level SSR DC Overview
The 8 Channel 3-24V Solid State Relay Module (H3MB-052D) is designed to switch DC loads of up to 50 V at 2 A per channel using low-voltage DC control signals. With phototriac isolation and built-in resistive fuses, it delivers reliable, long-life switching without mechanical wear.
Key Features of 8 Channel 3-24V Relay Module Solid State High Level SSR DC
- 8 independent SSR outputs, each handling up to 50 V DC at 2 A
- Wide control voltage range: 3–24 V DC high-level trigger
- Low power consumption: 160 mA at 24 V DC supply
- Phototriac isolation between input and output for enhanced noise immunity
- Integrated resistive fuse protection on each channel to guard against overloads
- Solid-state design offers silent, fast switching and extended service life
- Genuine product, fast shipping from Zbotic across India
Applications and Use Cases
- Automating DC lighting circuits and LED strip installations
- Controlling small DC motors or actuators in robotics projects
- Battery management and solar panel switching where silent operation is needed
- Test benches and prototype rigs requiring precise on/off control
- Integration with PLCs, microcontrollers or single-board computers for industrial control
- Security systems and door-lock mechanisms driven by low-voltage controllers
How to Use 8 Channel 3-24V Relay Module Solid State High Level SSR DC
Connect a stable 3–24 V DC supply to the module’s VCC and GND pins, then wire each input pin to your control source (microcontroller, PLC, etc.) with a high-level signal (3–24 V). Attach the DC load (up to 50 V, 2 A) between the module’s output terminal and ground. The built-in resistive fuse on each channel automatically protects against overcurrent events.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What trigger voltage range does this SSR module support?
The module accepts high-level DC inputs from 3 V up to 24 V to activate each relay channel.
Can I switch 12 V LED strips with this relay board?
Yes. Each channel switches up to 50 V DC at 2 A, making it suitable for 12 V LED strips as long as the strip’s current draw does not exceed 2 A per channel.
How does the built-in resistive fuse work?
Each output channel includes a resistive fuse that limits excessive current during overloads. In case of a fault, it protects both the load and the SSR without the need for external fuses.
