This is the 12V variant of the ESP8266 ESP-01 12V 4, Channels WiFi Relay, Module Things Smart, Home Remote Control, Switch in Relay Modules. Available at ₹644.28 (₹546.00 + GST) with free shipping across India.
ESP8266 ESP-01 12V 4, Channels WiFi Relay, Module Things Smart, Home Remote Control, Switch
Experience seamless wireless control with the WiFi Relay Module, featuring an integrated ESP8266 WiFi module and microcontroller. This module enables relay control via serial port instructions sent to the cell phone APP within the local area network (LAN), offering convenient wireless control over connected devices.
Features:
- ESP8266 WiFi Module: Equipped with an ESP8266 WiFi module and microcontroller, allowing for wireless relay control within the local area network (LAN) via cell phone APP.
- 4-Channel Relay: Features four relay channels capable of activating devices operating at up to 250V AC and 30V DC, providing versatile control options for various applications.
- LED Indicator: Includes a red power activation LED that lights up when a signal is received on the IN pin, providing visual feedback on the module’s state.
- Audible Feedback: Provides audible feedback with a click sound when the relay triggers, connecting the output pins.
- Easy Configuration: Requires configuration via UART prior to full operation. Once programmed and powered, the module operates autonomously, making it ideal for IoT-based projects.
- Power Connection: Connect the positive and negative poles of a 12V/1A power adapter to the IN and IN- pins of the module, respectively.
- Install Android APP: Install the “ESP Touch-Demo” app on an Android mobile terminal. For initial configuration, use Work Mode 2 to configure the WiFi account number and password for the ESP-01 module.
- Relay Control: Install the “Easy TCP-20” app on the Android mobile terminal, a TCP transmission tool used to send relay control instructions. Click on “SWITCH” and enter the relay control instructions, names, and contents (in HEX format) in the gray blocks interface.
- Transmission Distance: Maximum stable transmission distance of 100m in an open environment when the mobile phone is mounted on the WiFi module. The transmission distance may vary depending on the signal strength of the router when both the WiFi module and mobile phone are connected to the router simultaneously.
- Smart Config Technology: Utilizes Smart Config technology in the ESP-01 WiFi module to complete account and password configuration via the mobile phone APP, with a memory function for configured username and password.
- Relay Rating: Onboard 12V relay capable of handling 10A at 250V AC or 30V DC, with a lifespan of up to 100,000 continuous switching cycles. Features diode discharge protection and short response time.
- Board Indicator: Includes mode selection and real-time working status indicator for enhanced monitoring and control.
- UART Debug Interface: Reserved UART debug interface and STM8 SWIM program download interface for debugging and program development purposes.
Enhance your project’s wireless control capabilities with the WiFi Relay Module, offering easy configuration, reliable performance, and versatile relay control options for IoT-based applications.
Specifications:
-
Transmission Distance(m) 400 Relay Channel 4 Trigger Voltage (VDC) 12 Switching Voltage (VAC) 250@10A Switching Voltage (VDC) 30@10A Baud Rate (bps) 9600 Shipping Weight 0.01 kg Shipping Dimensions 7 × 4 × 2 cm
Package Includes:
1 x ESP8266 ESP-01 12V 4, Channels WiFi Relay, Module Things Smart, Home Remote Control, Switch
ESP8266 ESP-01 12V 4, Channels WiFi Relay, Module Things Overview
This ESP8266 ESP-01 WiFi Relay Module combines an ESP8266 microcontroller with four high-power relay channels on a single 12 V board. It enables wireless switching of AC or DC devices within your home or office network via a smartphone app.
Key Features of ESP8266 ESP-01 12V 4, Channels WiFi Relay, Module Things
- Integrated ESP8266 ESP-01 WiFi module with up to 400 m transmission distance in open space
- Four SPDT relay channels, each rated 250 VAC/10 A and 30 VDC/10 A
- 12 VDC trigger voltage powered by common 12 V adapters
- 9600 baud serial communication for fast and reliable control
- LED status indicators for each relay channel
- Genuine product, fast shipping from Zbotic
Applications and Use Cases
- Home automation: switch lights, fans or garage doors via smartphone
- Industrial prototyping: remotely drive pumps, motors or solenoid valves
- Security systems: trigger alarms or cameras on demand
- Agriculture: automate irrigation valves and greenhouse fans
- Smart office: control projectors, coffee machines or HVAC units
How to Use ESP8266 ESP-01 12V 4, Channels WiFi Relay, Module Things
Wire a stable 12 VDC supply to VCC and GND, connect your smartphone or PC to the same LAN, then launch the companion app. Use the app or a USB-TTL adapter at 9600 baud to send AT commands and toggle each relay channel on or off.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Can I access the relay module over the internet?
This module works within a local area network by default. To control it from outside, configure your router for port forwarding or use a VPN to connect securely to your LAN.
What loads can I switch with these relays?
Each channel handles up to 250 VAC at 10 A or 30 VDC at 10 A. Exceeding these ratings may damage the relay contacts and reduce lifespan.
Is any additional software needed to use the module?
No additional drivers are required. You can control the relays using standard AT commands via any USB-TTL adapter at 9600 baud or through the provided smartphone app.
