Description:
The APM2.5 NEO-M8U GPS Module GYGPSV1-8M is optimized for cost-sensitive applications, while NEO-M8U/M8Q provides the best performance and easier RF integration. The NEO-M8U offers high performance also at low power consumption levels. The futureproof NEO-M8U includes an internal Flash that allows future firmware updates. This makes NEO-M8U perfectly suited to industrial and automotive applications.
The NEO-M8 series of concurrent GNSS modules are built on the high performing M8 GNSS engine in the industry proven NEO form factor.NEO-M8U provides the best performance and easier RF integration. The NEO-M8U offers high performance also at low power consumption levels. The future-proof NEOM8U includes an internal Flash that allows future firmware updates. This makes NEO-M8U perfectly suited to industrial and automotive applications.
Features:
- The ceramic antenna provides a very strong signal
- With LED indicator lamp
- The default baud rate: 9600.
- Flash memory: 64KB
- With data backup battery.
- LED signal indicator.
- Compatible with various flight controller module.
- EEPROM save the configuration parameter data when power-down.
-
Assistance AssistNow GNSS Online
-
AssistNow GNSS Offline (up to 35 days)
-
AssistNow Autonomous (up to 6 days)
-
OMA SUPL & 3GPP compliant
-
Oscillator TCXO
-
Built-in RTC crystal
-
Anti-jamming Active CW detection and removal.
-
Extra onboard SAW bandpass filter
-
Memory Flash
-
Supported antennas Active and passive
-
Odometer Travelled distance
-
Data-logger For position, velocity, and time
Specifications:
| Receiver Type | 72-channel Ublox M8 engine. |
|---|---|
| Input Supply Voltage (VDC) | 3 ~ 5 |
| Main Chip | Ublox NEO-M8U |
| Sensitivity (dBm) | 156, Cold Start (without aiding): -147 dBm |
| Position Accuracy (Meter) | 2, 2.5 |
| Acceleration (g) | <4 |
| Navigation Update Rate | up to 18 HZ. |
| Operating Temperature (°C): | -45 to 105 |
| Tracking Sensitivity (dBm) | -161 dBm |
| Co-Ordinate System | WGS-84 |
| Flash memory | 64KB |
| Capture Time | 0.1s Average |
| Avg Cold Start Time (s) | 30 |
| Warm Start Time (s) | 1 |
| Boot Time | 1S |
| Maximum Altitude (m) | 18000 |
| Dimensions in mm (LxWxH) | Antenna: 26 x 26 x 9, Module: 26 x 36 x 4 |
Package Includes:
- 1 x APM 2.5 NEO M8U GPS Module.
- 1 x Ceramic Active Antenna.
IoT Cold Chain Monitoring: Temperature Tracking for Food
Table of Contents Why Temperature Monitoring Matters Sensor Selection Guide Hardware Assembly and Wiring Firmware Development Cloud Data...
Read More →
Bluetooth Switch: Phone-Controlled Relay
Understanding the bluetooth switch is essential for anyone working with electronics in India. This comprehensive guide covers Bluetooth-controlled...
Read More →
Crowbar Circuit: Overvoltage Protection for Your Electronics
Crowbar Circuit: Overvoltage Protection for Your Electronics Every power supply can fail. Voltage regulators go short-circuit. Feedback loops...
Read More →Technical Specifications
| Model | NEO-M8U |
|---|---|
| SKU | AI7871 |
| Weight | 0.02 kg |
| Availability | In Stock |
Applications & Use Cases
The NEO-M8U GPS Module with Ceramic Active Antenna is a versatile iot and wireless used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
