This is the Blue variant of the HC-05 6pin Bluetooth Module with Button in Bluetooth and NRF Modules. Available at ₹272.58 (₹231.00 + GST) with free shipping across India.
Description:
The HC-05 6 Pin Wireless Serial Bluetooth Module is designed for use with any microcontroller, utilizing the UART protocol for easy wireless data transmission.
The HC-06 module operates as a slave-only device, allowing it to connect to most Bluetooth-enabled phones and computers. However, it cannot connect to other slave devices like keyboards or other HC-06 modules. To connect with additional slave devices, a master module like the HC-05 is required, as it supports both master and slave functionalities.
Features:
- HC‐05 module is an easy-to-use Bluetooth SPP (Serial Port Protocol) module, designed for transparent wireless serial connection setup. The HC-05 Bluetooth Module can be used in a Master or Slave configuration, making it a great solution for wireless communication.
- Typical ‐80dBm sensitivity.
- Up to 4dBm RF transmit power.
- 3.3 to 5 V I/O.
- PIO(Programmable Input/Output) control.
- UART interface with programmable baud rate.
- With integrated antenna.
- With edge connector
Applications:
- Embedded Projects.
- Industrial Applications.
- Computer and Portable Devices.
- GPS receiver.
Specification:
| Input Supply voltage (V) | 3.6 ~ 6 |
|---|---|
| Input current (mA) | 50 |
| Maximum Operating Range (m) | 10 |
| Operating Frequency | 2.4GHz ISM band |
| Modulation | GFSK (Gaussian Frequency Shift Keying) |
| Emission power | 4dBm, Class 2 |
| Sensitivity | -84dBm at 0.1% BER |
| Operating Temperature (℃) | -20 ~ +75 |
| Length (mm): | 43 |
| Width (mm): | 16.5 |
| Height (mm): | 7 |
Package Includes:
1 x HC-05 6pin Bluetooth Module with Button
Arduino Real Time Clock DS3231: Accurate Timekeeping Projects
Table of ContentsWhat Is the DS3231 RTC Module?Wiring the DS3231 to ArduinoSetting the Time: First-Time ConfigurationReading Time and...
Read More →
ESP8266 NodeMCU Getting Started Guide India
The ESP8266 NodeMCU getting started guide covers everything you need to know to begin building WiFi-connected projects with...
Read More →
Arduino Debouncing: Clean Button Input Techniques
Table of ContentsIntroductionComponents and Hardware SetupWiring Diagram and ConnectionsComplete Code with ExplanationCustomization and ImprovementsTroubleshooting Common IssuesAdvanced Features and...
Read More →Technical Specifications
| Model | HC-05 |
|---|---|
| Pin Count | 6-pin |
| Interface / Protocol | Bluetooth |
| Color | Blue |
| SKU | AI0016 |
| Weight | 0.01 kg |
| Availability | In Stock |
Applications & Use Cases
The HC-05 6pin Bluetooth Module with Button is a versatile bluetooth and nrf modules used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
