XH-M131 DC 24V Light Control Switch Photoresistor Relay Module
Unlock versatile light detection and brightness control capabilities with our feature-packed module. This module serves as an essential tool for various applications, including light detection, brightness adjustment, and automated control systems. Equipped with intuitive features and durable construction, it’s an indispensable component for your automation projects.
Features:
- Power and Relay Indicator Lights: Keep track of module status with the integrated red and blue indicator lights. The red light signals power activation, while the blue light indicates relay operation, ensuring easy monitoring at a glance.
- Adjustable Sensitivity: Tailor the module’s light sensitivity to your specific needs using the onboard potentiometer. This adjustable feature allows precise customization for optimal performance in different lighting conditions.
- Reliable Protection: Benefit from built-in anti-reverse functionality, safeguarding the module from potential damage caused by reverse power supply connections. Enjoy peace of mind knowing your equipment is protected against common electrical mishaps.
- Versatile Output Ports: The module offers three output ports, providing flexibility for connecting to various devices and systems. This versatility enhances compatibility and facilitates seamless integration into your projects.
- Easy Installation: Simplify installation with four M3 screw mounting holes, enabling quick and convenient setup in your desired location. Whether you’re a beginner or an experienced user, our module’s user-friendly design ensures hassle-free installation and operation.
Relay Pinouts:
- Normally Open (NO): Connects to the external circuit when the relay is activated.
- Common Terminal (COM): Provides a common connection point for the relay.
- Normally Closed (NC): Connects to the external circuit when the relay is deactivated.
Enhance your automation systems with our versatile module, designed to deliver reliable performance and intuitive operation. Whether you’re implementing automated lighting controls or creating customized solutions for your projects, our module provides the flexibility and functionality you need to succeed.
Specifications:
| Module Name | Photosensitive Relay Module |
|---|---|
| Module Model | XH-M131 |
| Trigger Voltage (VDC) | 24 |
| Switching Voltage (VAC) | 250@10A |
| Switching Voltage (VDC) | 30@10A |
| Output Type | Output Switch |
| Dimension | 30.5MM*53MM |
| Shipping Weight | 0.021 kg |
| Shipping Dimensions | 6 × 4 × 2 cm |
Package Includes:
1 x XH-M131 DC 24V Light Control Switch Photoresistor Relay Module
XH-M131 DC 24V Light Control Switch Photoresistor Relay Overview
The XH-M131 DC 24V Light Control Switch Photoresistor Relay Module is a photosensitive relay board designed to switch loads automatically based on ambient light levels. Ideal for integrating into automation systems, it detects brightness changes and toggles a 20 A relay output without additional controllers.
Key Features of XH-M131 DC 24V Light Control Switch Photoresistor Relay
- Operates on a 24 VDC supply for stable power input
- Photoresistor sensor enables automatic light detection and switching
- High-capacity relay output rated up to 20 A for heavy-duty loads
- Red LED indicates power on, blue LED shows relay activation
- Compact, durable PCB design for easy mounting and integration
- Genuine product with fast shipping from Zbotic across India
Applications and Use Cases
- Automatic streetlight or garden lamp activation at dusk and dawn
- Industrial signage illumination control to save energy during daylight
- Greenhouse or indoor horticulture light management
- Solar lighting systems for off-grid pathways or security lights
- Energy-efficient control of indoor corridor or warehouse lighting
How to Use XH-M131 DC 24V Light Control Switch Photoresistor Relay
Mount the module where its photoresistor sensor can receive ambient light, connect a regulated 24 VDC supply to the power terminals, and wire your lighting or other load through the relay output contacts. When light falls below or rises above the module’s detection threshold, the blue LED will illuminate to show relay activation, switching your load on or off automatically.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What supply voltage does the XH-M131 require?
The XH-M131 module is designed to operate on a 24 VDC input. Ensure a stable 24 V power source to guarantee accurate light detection and reliable relay switching.
How much load current can the relay handle?
This photoresistor relay module features a switch capable of handling up to 20 A on DC loads. It is suitable for controlling high-current lighting circuits and resistive devices.
What do the red and blue LEDs signify?
The red LED indicates that the module is powered on and ready, while the blue LED lights up when ambient light conditions trigger the relay to close, signaling that your connected load is active.
