This product is an industrial 32-ch relay module controlled via RS485 bus, adopting the Modbus RTU protocol. It includes built-in protection circuits such as power supply isolation, magnetical isolation, resettable fuse, and TVS diode, and comes with an ABS case.
The Modbus RTU 32-Ch Relay is very easy to use. With its fast communication, stability, reliability, and safety, it is an ideal choice for industrial control equipment and applications requiring high communication performance.
Applications:
- Industrial Control
- Smart Home
- Smart Agriculture
- Breeding and Farming
Features:
- Configurable device address (1~255) allowing cascading of multiple devices on the RS485 bus
- Supports flash-on and flash-off functions, enabling timed relay activation
- Onboard voltage regulator chip supporting 7~36V wide power supply
- Unibody power supply isolation providing stable isolated voltage without extra supply
- Unibody magnetical isolation for signal isolation, high reliability, and low power consumption
- Resettable fuse and TVS to suppress surge and transient voltages, offering over-current, over-voltage, lightning, and anti-static protection
- Optocoupler isolation preventing interference from high-voltage circuits
- Dedicated relay driver chip with freewheeling diode protection for stronger and more stable driving ability
- Reverse-proof circuit preventing damage from incorrect wiring
- High-quality relay, contact rating ≤10A 250VAC/30VDC
- Rail-mounted ABS case, easy and safe to install
- Three LEDs indicating MCU status and signal transmission states
Specifications:
| Model | Relay Module |
|---|---|
| No. of Channels | 32 |
| Operating Voltage (VDC) | 7 to 36 |
| Communication Mode | RS485 |
| Baud Rate | 4800, 9600, 19200, 38400, 57600, 115200, 128000, 256000 |
| Contact Form | 1NO 1NC |
| Contact Rating | ≤10A 250VAC/30VDC |
| Communication Protocol | Standard Modbus RTU protocol |
| RS485 Address | 1~255 |
| LED Indicator (Y/N) | RXD: Lights when receiving, STA: Flashes during normal MCU operation, TXD: Lights when sending |
Package Includes:
-
1 × Waveshare Modbus RTU 32-Ch Relay Module, RS485 Interface, With Multiple Isolation Protection Circuits
