ULN2003 Driver Module Stepper Motor Driver
The ULN2003 Driver Module is a compact and user-friendly Stepper Motor Driver. It employs the ULN2003 driver chip to enhance the control signal from an Arduino. This cost-effective and lightweight option is widely utilized for operating and managing stepper motors in small applications.
Note: Color of PCB of may vary according to Manufacturer
HOW TO CONTROL STEPPER
The step motor is to a machine to convert pulse to angular displacement. So if you give stepper driver a certain pulse signal, it will drive step motor to a certain angle. you can control the angle the stepper moved by the number of the pulse. And you also can control the speed of the stepper rotate by the frequency of the pulse. The following picture is the schematic of the stepper driver.
The following picture is the control signal to drive a 28BYJ48 stepper to rotate 1/4096 circle.
| line | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 |
|---|---|---|---|---|---|---|---|---|
| red | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| orange | 1 | 1 | 0 | 0 | 0 | 0 | 0 | 1 |
| yellow | 0 | 1 | 1 | 1 | 0 | 0 | 0 | 0 |
| pink | 0 | 0 | 0 | 1 | 1 | 1 | 0 | 0 |
| blue | 0 | 0 | 0 | 0 | 0 | 1 | 1 | 1 |
Note: We have small size 28BYJ-48 Stepper Motor available in our shop which can be coupled with this ULN2003 Driver Module, click below to buy
28BYJ-48 Stepper Motor
Features :
- 4-way signal indicator
- Chip all the pins have Input leads Mounted for easy connection to use
- XH-5P socket can be connected directly 28BYJ-48 Model stepper motor
Package Includes :
1 x ULN2003 Driver Module Stepper Motor Driver(Blue)
ULN2003 Driver Module Stepper Motor Driver Overview
The ULN2003 Driver Module Stepper Motor Driver is a compact board built around the ULN2003 Darlington transistor array to drive unipolar stepper motors. Designed for seamless connection with 28BYJ-48 stepper motors via an XH-5P socket, it accepts 5–12 V input and provides four-channel control with LED indicators for each phase.
Key Features of ULN2003 Driver Module Stepper Motor Driver
- Wide 5–12 V power supply range for compatibility with common power sources
- Built-in ULN2003 driver chip boosts microcontroller signals for reliable motor torque
- 4-way LED indicators show real-time phase activation status
- All control pins broken out to input headers for easy wiring to Arduino, Raspberry Pi or other boards
- XH-5P socket allows plug-and-play connection to 28BYJ-48 unipolar stepper motors
- Fast shipping from Zbotic across India
Applications and Use Cases
- DIY robotic arms requiring precise rotational control
- Automated camera sliders and pan/tilt rigs for smooth motion
- Small CNC machines and engraving setups for hobbyists
- Educational electronics kits teaching stepper motor driving
- Home automation projects like motorized blinds or valves
How to Use ULN2003 Driver Module Stepper Motor Driver
Connect the module’s VCC pin to a 5–12 V power source and GND to your system ground. Plug the 28BYJ-48 stepper motor into the XH-5P socket, then wire IN1–IN4 to your microcontroller’s digital output pins. Upload a step sequence (e.g., full-step or half-step) to your controller; each pulse advances the motor by a fixed angle, and the onboard LEDs will light to indicate which coils are energized.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What voltage does the ULN2003 driver module require?
The module operates on a DC supply between 5 V and 12 V. Ensure your power source can deliver sufficient current for your stepper motor’s rated draw.
Can I use the ULN2003 module with a 28BYJ-48 stepper motor?
Yes—the XH-5P connector is designed specifically for 28BYJ-48 unipolar stepper motors, allowing plug-and-play operation without additional wiring.
What do the 4 signal indicator LEDs indicate?
Each LED corresponds to one of the motor coils. When an LED lights up, its associated coil is energized, helping you visually confirm the stepping sequence.
