Looking for Tb6560 Board? TB6560 Driver Board 3A CNC Router Single 1 Axis Controller Stepper Motor is available at Zbotic with fast shipping across India.
Product Description:
This product is a stepper motor driver board that can control one axis of a CNC router. It has a high-speed optocoupler isolation for input signal and a large heat sink for good heat dissipation. It also has adjustable semi-flow mode and current, with various options for setting them.
The TB6560 Driver Board 3A CNC Router Single 1 Axis Controller Stepper Motor is a user-friendly module that does not require any special instructions. It has a unique design that allows adjusting the semi-flow mode and the semi-flow current, unlike other products on the market.
This driver module uses the TB6560AHQ new original chip, which has low voltage shutdown, overheating stop and overcurrent protection features to ensure optimal performance.
The TB6560 stepper motor control circuit is a common and versatile circuit that can control a 2-phase motor (10 – 35VDC) with a maximum output of 3A. It is suitable for stepper motor control, CNC machine applications or precision mechanical systems.
Features:
- Current level by adjustable to meet your various application requirements.
- Automatic semi-flow adjustable.
- Using 6N137 high-speed optical coupling to ensure high speed without losing a step.
- Board printed setup instructions.
- Using thick fine-toothed radiator, good heat dissipation.
- For 42,57,86 Stepper within 3A 2/4 -phase / 4 wire / 6 wire stepper motor, not fit for more than 3A stepper motor.
- Excitation Mode: synchronizing, half step, 1/8 step, 1/16 step, a maximum of 16 segments.
- Automatic half-decay.
Package Includes :
1 x TB6560 Driver Board
TB6560 Driver Board 3A CNC Router Single 1 Axis Controller Overview
The TB6560 Driver Board 3A CNC Router Single 1 Axis Controller is a dedicated stepper motor driver module designed to control one axis of a CNC machine or similar setup. It provides reliable current regulation and signal isolation for smooth, precise motion control in DIY and professional CNC applications.
Key Features of TB6560 Driver Board 3A CNC Router Single 1 Axis Controller
- TB6560AHQ driver chip delivering up to 3 A phase current
- Wide input voltage range of 10–35 V DC (nominal 24 V)
- Large integrated heat sink for effective thermal dissipation
- 6N137 high-speed optocoupler ensures clean, isolated input signals
- Adjustable microstep resolution and phase current via onboard potentiometers
- Genuine module dispatched with fast shipping from Zbotic
Applications and Use Cases
- Driving the X, Y, or Z axis on desktop CNC routers
- DIY CNC plasma cutters or milling machines
- Single-axis motion control in laser engraving systems
- Stepper-based linear actuators for automation projects
- Custom robotics requiring isolated, high-current stepper control
How to Use TB6560 Driver Board 3A CNC Router Single 1 Axis Controller
Connect a 10–35 V DC power supply to the VCC and GND terminals, wire your stepper motor to the A+/A– and B+/B– outputs, and feed STEP and DIR signals into the opto-isolated inputs. Use the onboard potentiometers to set the desired microstep resolution and phase current, then test movement commands via your CNC controller software.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
How do I adjust the stepper current on the TB6560 driver board?
Use the onboard current-setting potentiometer labeled I-ADJ to fine-tune the phase current. Turn clockwise to increase and counterclockwise to decrease, monitoring motor temperature to avoid overheating.
What power supply voltage should I use?
The driver board supports 10–35 V DC. For optimal torque and stable operation, a 24 V regulated supply is recommended.
How is input isolation achieved on this module?
The TB6560 board utilizes a 6N137 high-speed optocoupler to isolate the STEP/DIR input signals from the power stage, minimizing electrical noise and preventing signal interference.
