Name: JGB37-520 DC24V 600RPM/MIN Miniature Forward and Reverse Brushed DC Speed Reducer Motor
Brand: Zbotic
SKU: AI3739
Price: 520.38 INR
Availability: OutOfStock
Rating: 4.64 (11 reviews)

This is the Red variant of the JGB37-520 DC24V 600RPM/MIN Miniature Forward and Reverse Brushed DC Speed Reducer Motor in Motors & Drivers & Pumps & Actuators, Brushed / Brushless DC motor Driver, Motor Drivers. Available at ₹520.38 (₹441.00 + GST) with free shipping across India.

Looking for Jgb37 Motor 600rpm? JGB37-520 DC24V 600RPM/MIN Miniature Forward and Reverse Brushed DC Speed Reducer Motor is available at Zbotic with fast shipping across India.

DC motor is equipped with a brushed motor, which makes the motor more stable and durable. This gearbox motor has high performance and excellent electrical conductivity, which can improve the service life of the product 12V Reduction motor for small smart device parts, like a Full vending machine, small lock, smart toy, etc.

This large and powerful JGB37-520 DC gear motor is available in a wide range of operating voltages and speeds, suitable for almost any project.

Features:

Small gear motor with low speed, low noise, and high torque.
The geared motor adopts pure copper winding, which has the characteristics of low heat generation and low loss.
The metal gearbox has the characteristics of wear resistance and rust resistance, and the motor has a long service life.
The high-torque gear motor has a thickened magnet with a strong magnetic field and strong anti-interference.

Specification:

Model: PB37-520-7
Rated Voltage: 24V
Revolving Speed: 600 RPM
Rated Torque: 0.15 kg. cm
Stall Torque: 0.6 kg. cm
Rated Current: 100 mA
Stall Current: 1.2A
Total Length(LxWxH) : 77x37x37mm
Gear Material: Full Metal
Shaft Size : 6 x 15mm(D*L)
Gearbox length(L) :27mm
Shaft Type : D Type
Net Weight: 0.1911kg

Applications:

Vending machines
panoramic cameras
Slot machines
Money detectors
Coin refund devices
Automatic doors
Peritoneal machines
Toys, etc.

About Jgb37 Motor 600rpm

JGB37-520 DC24V 600RPM/MIN Miniature Forward and Reverse Brushed DC Speed Reducer Motor is available at Zbotic, India’s trusted electronics and robotics store. Manufactured by Generic, this product is designed for hobbyists, students, and professionals working on electronics, robotics, and DIY projects.

Product Details

Brand: Generic
SKU: AI3739
Category: Motors & Drivers & Pumps & Actuators

Why Buy from Zbotic?

Zbotic offers a wide range of electronics components, development boards, sensors, and robotics parts. All products are quality-checked and shipped within 24 hours. Free shipping on qualifying orders. We offer COD (Cash on Delivery) and secure online payment options. Our customer support team is available to help with technical queries about Jgb37 Motor 600rpm and other products.

Applications

Jgb37 Motor 600rpm can be used in a variety of projects including Arduino projects, Raspberry Pi builds, drone assembly, 3D printing, IoT applications, and educational experiments. Whether you are a beginner or an advanced user, this component provides the reliability and performance you need. Order your Jgb37 Motor 600rpm today and start building.

JGB37-520 DC24V 600RPM/MIN Miniature Forward and Reverse Overview

The JGB37-520 DC24V 600RPM/MIN is a compact brushed DC speed reducer motor designed for low-speed, high-torque applications. With forward and reverse capability at 24 V DC, it’s ideal for small smart devices, vending mechanisms, locking systems and miniature robotic projects.

Key Features of JGB37-520 DC24V 600RPM/MIN Miniature Forward and Reverse

600 RPM output speed at 24 V DC for precise motion control
Forward and reverse operation by swapping supply polarity
Brushed motor with pure copper winding for stable performance and long life
Integrated gearbox delivers high torque and low noise
Compact JGB37 housing fits tight installation spaces
Genuine product with fast shipping across India from Zbotic

Applications and Use Cases

Drive mechanism for small vending machines and automated dispensers
Actuator for electronic door locks and security latches
Power source for smart toys, miniature vehicles and educational robots
Rotary drive in micro conveyor belts or turntables
Positioning motor in camera sliders and pan/tilt heads
Gear reduction for precision dosing pumps and fluid metering

How to Use JGB37-520 DC24V 600RPM/MIN Miniature Forward and Reverse

Mount the JGB37-520 to your chassis using the gearbox’s mounting holes, then connect a regulated 24 V DC supply to the two motor leads. To reverse direction, simply swap the positive and negative wires. Secure all connections, avoid overloading beyond its rated torque, and use PWM speed control if variable speed is needed.

Why Buy from Zbotic?

Genuine Products: All items sourced from authorized distributors
Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
Free Shipping: Free delivery on qualifying orders
COD Available: Cash on Delivery, UPI, cards, net banking
Technical Support: Expert help for setup and troubleshooting
Easy Returns: Hassle-free replacement for defective products

Frequently Asked Questions

How do I reverse the rotation of the JGB37-520 motor?

To reverse the motor direction, disconnect power and swap the 24 V DC supply leads. The built-in brushed design allows simple polarity reversal without additional circuitry.

What torque can this reducer motor deliver?

The JGB37-520 gearbox multiplies the motor’s output to provide high starting torque suitable for small locks and robotic drives. Exact torque varies with load, but it typically exceeds 1 kg·cm under no-load 600 RPM conditions.

Is this motor suitable for continuous operation?

Yes, the JGB37-520 is rated for continuous duty at 24 V, provided it runs within its torque and thermal limits. Ensure adequate ventilation and avoid sustained stall conditions to maximize lifespan.

Tags: Buy Online India Motor Driver Zbotic

Technical Specifications

Model	JGB37-520
Operating Voltage	24V
Speed	600 RPM
Color	Red
SKU	AI3739
Weight	0.17 kg
Availability	Out of Stock

Applications & Use Cases

The JGB37-520 DC24V 600RPM/MIN Miniature Forward and Reverse Brushed DC Speed Reducer Motor is a versatile brushed / brushless dc motor driver used across a wide range of applications including robot motor control, DC motor speed regulation, H-bridge circuits, electric vehicle drives, and conveyor belt control.

Common use cases:

Bidirectional motor control for a robot
PWM speed control of a DC motor
Building a motorized platform

This product is ideal for robotics engineers and motor control enthusiasts.

Technical Tip: L298N is a classic dual H-bridge driver. For higher efficiency, consider MOSFET-based drivers like BTS7960.

Shipping & Delivery

Free shipping on orders above ₹999 across India
Dispatched within 1-3 business days
Expected delivery: 3-7 business days depending on location
Secure packaging to ensure safe transit of electronic components

Weight	0.17 kg

15 Days Warranty

Please note that this item is only covered by a standard supplier warranty against manufacturing defects for a period of 15days from the time of delivery. It is important to understand that only manufacturing defects are covered under this warranty, and any other issues will not be considered for reimbursement or replacement. We strongly advise inspecting the product upon delivery to ensure it meets your expectations. In case of any manufacturing defects, we guarantee reimbursement or replacement.
