This is the 40V variant of the DC-DC5-40V to 5V 1A Buck Step Down Converter Module with PIN in Buck Converter, Buck Boost Voltage Regulators. Available at ₹149.86 (₹127.00 + GST) with free shipping across India.
Looking for Dc-dc5 Module 40v? DC-DC5-40V to 5V 1A Buck Step Down Converter Module with PIN is available at Zbotic with fast shipping across India.
This device operates within an input voltage range of 5 to 40 volts and delivers up to 90% efficiency. It features over-current and over-temperature protection for safe operation. Powered by a high-performance controller that regulates current at a fixed frequency, it is ideal for applications such as battery chargers, home automation, and other high-voltage electrical equipment.
Features:
- High efficiency up to 90%.
- 5-40V adjustable input voltage range.
- With over-current and over-temperature protection, safe for use.
- It uses high performance fixed frequency current control mode controller as the core.
- Suitable for Battery chargers, home automation, and other high voltage electrical equipment.
Specification:
| Input Voltage (V) | 5~40V |
|---|---|
| Output | 5V |
| Max. Output Current (A) | 1A |
| Efficiency | 76-90% |
| Material | Electronic Component |
| Color: | Green |
| Size(mm) | 18.3mm x 10.2mm x 6.7mm |
| Shipping Weight | 0.02 kg |
| Shipping Dimensions | 2 × 2 × 1 cm |
Package Includes:
1 x DC-DC5-40V to 5V 1A Buck Step Down Converter Module with PIN
DC-DC5-40V to 5V 1A Buck Step Down Converter Module with PIN Overview
This DC-DC5-40V to 5V 1A Buck Step Down Converter Module with PIN is a compact switching regulator designed to convert input voltages between 5V and 40V down to a stable 5V output at up to 1A. It’s ideal for integrating into electronic projects and high-voltage systems where a reliable 5V supply is required.
Key Features of DC-DC5-40V to 5V 1A Buck Step Down Converter Module with PIN
- Wide input range: accepts 5–40V DC for versatility across power sources
- Fixed 5V output at maximum 1A current for powering 5V devices
- High conversion efficiency of 76–90% minimizes heat generation
- Built-in over-current and over-temperature protection for safe operation
- High-performance fixed-frequency current control mode controller core
- Fast shipping from Zbotic across India for quick project deployment
Applications and Use Cases
- Powering microcontroller boards (Arduino, ESP series) from 12–24V sources
- Supplying 5V to Raspberry Pi or single-board computers in automotive and solar setups
- Driving low-power LED strips and lighting modules
- Integrating into battery charger circuits for stable reference voltage
- Providing regulated 5V supply for CNC controllers or 3D printer electronics
- Use in home automation modules and IoT gateways requiring over-voltage resilience
How to Use DC-DC5-40V to 5V 1A Buck Step Down Converter Module with PIN
Connect your power source to the VIN+ and VIN– pins respecting polarity, then attach your 5V load to the VOUT+ and VOUT– pins. Ensure input voltage stays within 5–40V. Mount the module on a PCB or test board via its PIN headers, and add decoupling capacitors close to the load if needed. Power on and verify the 5V output before full deployment.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What input voltage range does this module support?
This buck converter accepts any DC input between 5V and 40V, making it suitable for automotive, battery, solar, and industrial supplies.
Is the output adjustable or fixed at 5V?
The module provides a fixed 5V output up to 1A. No onboard potentiometer is required for voltage adjustment.
How does the over-current and over-temperature protection work?
If the output current exceeds 1A or the module temperature rises above safe limits, the controller will automatically limit output or shut down to prevent damage.
Technical Specifications
| Model | DC-DC5-40V |
|---|---|
| Operating Voltage | 5V |
| Current Rating | 1A |
| SKU | AI3005 |
| Weight | 0.0026 kg |
| Availability | Out of Stock |
Applications & Use Cases
The DC-DC5-40V to 5V 1A Buck Step Down Converter Module with PIN is a versatile buck converter used across a wide range of applications including voltage step-down for electronics, battery-powered projects, LED driver circuits, microcontroller power supply, and solar power regulation.
Common use cases:
- Converting 12V car battery to 5V for USB devices
- Powering a Raspberry Pi from a drone battery
- Regulating solar panel output for charging
This product is ideal for electronics hobbyists, IoT developers, and power supply designers.
Technical Tip: Buck converters are more efficient than linear regulators (LM7805). Choose one rated for at least 1.5x your required current. Ensure input voltage is at least 2V above output.
