4 Channel 5V Relay Module Solid State High Level SSR DC Control 250V 2A with Resistive
Upgrade your control system with the 4-Channel 5V Solid State Relay Module, providing reliable switching capabilities for high-voltage AC loads from lower voltage DC control circuitry. This module features solid-state relay (SSR) technology, offering superior performance and durability compared to traditional mechanical relays.
Features:
- Solid State Relay Technology: Utilizes solid-state relay technology, consisting of an IR LED and a photo Triac sealed into a compact enclosure, ensuring noise-free operation and extended lifespan.
- 4-Channel Configuration: Control up to 4 independent loads with ease, providing versatility in your applications.
- High Load Capacity: Each channel supports loads of up to 2 amps at 240VAC, making it suitable for various lighting, holiday displays, and other applications.
- LED Indicator: Equipped with LED indicators for each relay, allowing for easy status monitoring.
- Assembled and Tested: The module comes assembled and has undergone electrical testing to ensure reliable performance.
- Wide Input Control Signal Voltage Range: Accepts input control signal voltage ranging from 0 to 20V, with specific thresholds for SSR activation:
- 0-0.5V: Low stage, SSR is OFF
- 0.5V – 2.5V: Unknown state
- 2.5V – 20V: High stage, SSR is ON
- Microcontroller Compatibility: Can be controlled directly by a microcontroller, providing seamless integration into your control setup.
- Convenient Input Connectivity: Features DC and DC- terminals for power connection, as well as IN1 to IN4 terminals for input control signal connection.
- Versatile Applications: Ideal for controlling various appliances and equipment with large currents, offering flexibility in usage scenarios.
Input Parts:
- DC: Connects to VCC for power supply according to the relay voltage.
- DC-: Connects to GND for the ground connection.
- IN1 – IN4: Individual relay module signal trigger points, active at the high level, facilitating precise control over each channel.
Enhance your control capabilities with the 4-Channel 5V Solid State Relay Module, providing reliable switching performance and versatility for a wide range of applications. Whether you’re controlling lighting systems, holiday displays, or other equipment, this module offers an efficient and durable solution for your needs.
Specifications:
| Part Number | G3MB-202P |
|---|---|
| Power supply | 5VDC/160mA |
| Trigger Voltage (VDC) | 5 |
| Switching Voltage (VAC) | 240@2A |
| Isolation | Phototriac |
| Zero Cross | Yes |
| Shipping Weight | 0.04 kg |
| Shipping Dimensions | 11.5 × 5 × 1 cm |
Package Includes:
1 x 4 Channel 5V Relay Module Solid State High-Level SSR DC Control 250V 2A with Resistive Fuse
