4 Channel 5V High Level Solid State Relay Module
The 5V 4-Channel SSR G3MB-202P Solid State Relay Module is a high-performance relay module designed to control up to 2A at 240VAC with a resistive fuse for added protection. Powered by Omron’s G3MB SSR relay components, each of the four relay channels is equipped with three distinct terminals: NO (Normally Open), COM (Common), and NC (Normally Closed).
Unlike traditional mechanical relays, Solid State Relays (SSRs) operate silently and have a much longer lifespan. They can be controlled via a digital input signal, and when the logic voltage is applied to the input, the NC terminal disconnects from the COM, cutting off conductivity. Meanwhile, the NO terminal connects to the COM, allowing current to flow. This simple mechanism makes it easy to turn connected loads on or off, depending on the wiring configuration, without the mechanical wear and noise associated with conventional relays.
Ideal for use in applications that require reliable, noise-free switching, the SSR module is perfect for controlling electronic devices in automation, lighting control systems, and more.
Input parts :
- DC+: connect power positive
- DC-: connect power negative
- CH1: relay module signal trigger point (Effective low-level trigger)
- CH2: relay module signal trigger point (Effective low-level trigger)
- CH3: relay module signal trigger point (Effective low-level trigger)
- CH4: relay module signal trigger point (Effective low-level trigger)
Features:
- Has been assembled, and the electrical test passed.
- Led indicator for each relay.
- Use it to control various appliances and other equipment with large current.
- It can be controlled directly by Microcontroller
- Input control signal voltage:
- 0-2.5V status low level, relay OFF
- 3-5V status high level, relay ON
- Blue KF301 terminal connection control line is more convenient.
Specification:
| Specification | Value |
|---|---|
| Number of Channels | 4 |
| Input Voltage | 5V |
| Control Signal Level | High-Level (TTL compatible) |
| Maximum Load Voltage | Determined by external load |
| Maximum Load Current per Channel | Determined by external load |
| Output Type | Solid State Relay (SSR) |
| Response Time | Typically microseconds to milliseconds |
| Isolation Voltage | Typically 1000V |
| Operating Temperature Range | Typically -40°C to +85°C |
| Dimensions | Varies depending on module design |
| Mounting | Typically PCB mount or screw terminals |
| Indicators | Typically LED indicators for each channel |
PACKAGE INCLUDES
- 1 X 4 Channel 5V High Level Solid State Relay Module
4 Channel 5V High Level Solid State Relay Module Overview
The 4 Channel 5V High Level Solid State Relay Module is a compact board that uses four Omron G3MB-202P solid state relays to switch AC loads silently and reliably. It’s designed for controlling up to 2A at 240VAC per channel with a TTL-compatible 5V high-level input, making it ideal for microcontroller-based automation.
Key Features of 4 Channel 5V High Level Solid State Relay Module
- Four independent SSR channels with NO, COM and NC terminals for versatile AC switching
- Driven by Omron G3MB-202P relays for 2A at 240VAC resistive load handling
- High-level trigger inputs operate at 5V with only 12.5mA input current each
- LED indicators on each channel for real-time status monitoring
- Fully assembled and electrically tested for immediate use out of the box
- Fast shipping across India from Zbotic’s warehouse
Applications and Use Cases
- Home automation: remotely switch AC lights, fans or heaters without mechanical noise
- Arduino and Raspberry Pi projects requiring AC load control
- Industrial control boards for small motors, solenoids and resistive heating elements
- DIY CNC or 3D printer upgrades for silent relay switching
- Laboratory equipment where flicker-free AC control is needed
How to Use 4 Channel 5V High Level Solid State Relay Module
Power the module with a 5V supply and connect the ground to your controller. Wire your AC load between the COM and NO (or NC for normally closed operation) terminals of each channel. Apply a 5V high-level signal to the input pins to switch the corresponding relay on, and observe the onboard LED indicator for status.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What is the maximum AC load this module can handle?
This module uses Omron G3MB-202P relays rated for up to 2A at 240VAC on each channel when switching resistive loads.
Can I drive the inputs directly from an Arduino?
Yes. Each input requires a 5V high-level signal with approximately 12.5mA current. You can connect them directly to Arduino digital outputs.
How do I choose between NO and NC terminals?
Use the NO (Normally Open) terminal when you want the circuit closed only after the relay is triggered. Use NC (Normally Closed) if you require the relay to open upon activation. COM is the common reference for both.
