Looking for 1 Channel Relay Module? 1 Channel Relay Module, 30A with Optocoupler, Isolation 5V Supports, High and Low Triger, （with Guide Rail） is available at Zbotic with fast shipping across India.
PRODUCT DESCRIPTION
This 1 channel 5V 30A relay control board module with optocoupler modules is compliant with international safety standards, control and load areas isolation trenches it has a single relay a genuine.
The inputs of 1 Channel 5V 30A Relay Module are isolated to protect any delicate control circuitry.
The power supply and relay instructions, lit, a disconnect are off. The input signal, signal, common Terminal and start conducting. It can be used as a single chip module for appliance control and work with both DC or AC signals where you can control the 220V AC load.
A wide range of microcontrollers such as Arduino, AVR, PIC, ARM and so on can control it.
This module comes with a Guide rail situated on the backside of it so we can adjust the module to a superior location.
Note: On the high level and low level-triggered mode, friends who do not understand, have a look
- High-level trigger refers to the signal voltage between input and trigger, can be understood as a signal input with VCC cathode short-circuit triggered away;
- Low-level trigger refers to the signal voltage between the input terminal and Earth OV trigger, can be understood as a signal input terminal and the GND negative electrode short circuit triggered is a way 1-channel relay module connection.
Features :
- High impedance controller pin
- Pull-down circuit for the avoidance of malfunction
- One normally closed contact and one normally open contact
- Triode drive, increasing relay coil
- Power supply indicator lamp
- Control indicator lamp
- With 4 fixed screw holes, hole diameter 3.1mm, convenient installation, and fixation
Package Include :
1 x 1 channel 5V 30A relay control board module (Guide rail)
1 Channel Relay Module, 30A with Optocoupler, Isolation 5V Overview
The 1 Channel Relay Module, 30A with Optocoupler, Isolation 5V is a single-channel switching board designed to control high-current loads up to 30 A. It features an optocoupler for complete isolation between the control circuitry and the high-voltage section, ensuring reliable operation in automation and appliance control projects.
Key Features of 1 Channel Relay Module, 30A with Optocoupler, Isolation 5V
- 30 A rated SPDT relay with 5 V coil voltage
- Optocoupler isolation protects microcontrollers from voltage spikes
- Supports both high-level and low-level trigger signals
- Includes DIN guide rail for easy mounting in control panels
- High-impedance input pin and pull-down resistor to avoid false triggering
- One normally closed (NC) and one normally open (NO) contact for versatile switching
- Genuine product, fast shipping from Zbotic
Applications and Use Cases
- Switching AC mains appliances (lights, fans, water pumps) up to 30 A
- Industrial automation for motor and heater control
- DIY home automation systems using Arduino or Raspberry Pi
- PLC-based control panels requiring isolated relay outputs
- Prototyping robotics projects with high-current loads
How to Use 1 Channel Relay Module, 30A with Optocoupler, Isolation 5V
Mount the module onto a DIN rail using the included guide rail, connect 5 V and GND from your microcontroller or power supply to the VCC and GND pins, then feed your trigger signal to the IN pin (high or low level). Wire your load between the COM and NO/NC terminals, apply the control signal to activate the relay, and monitor the onboard LED to confirm switching.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Can I trigger this module with both high and low signals?
Yes. The 1 Channel Relay Module supports both high-level and low-level trigger modes. You can configure the input pin pull-down to choose the desired trigger type.
What load types and voltages can it switch?
This relay module can handle AC loads up to 220 VAC or DC loads up to 30 VDC at currents up to 30 A, making it suitable for most home appliances and industrial devices.
How do I mount the module in my control cabinet?
The package includes a guide rail adapter compatible with standard DIN rails. Simply snap the module onto the rail for secure, professional installation.
