The Mini Motor Drive Shield Expansion Board L293D Module for Arduino UNO and MEGA 2560 is a high-voltage, high-current, four-channel driver designed to handle standard DTL or TTL logic levels. It is capable of driving inductive loads, such as relays, solenoids, DC motors, and stepper motors, as well as switching power transistors.
For ease of use, each pair of channels is equipped with an enable input, and a separate supply input for the logic allows operation at a lower voltage. The board also includes internal clamp diodes, making it suitable for switching applications with frequencies up to 5 kHz.
Features:
- Enable facility.
- Overtemperature protection.
- Logical “0” input voltage up to 1.5V(High noise immunity)
- Internal clamp diodes.
Specification
| Item Type: | L293D Motor Driver |
|---|---|
| Current Rating (A): | 0.6 to 1.2 |
| Voltage Rating (V): | 4.5 to 25 |
| Driver Model | L293D |
| Input Supply Voltage (V) | 4.5 ~ 25 |
| Output Current (A) | 0.6 |
| Continuous Current (A): | 1.2 |
| Switching Frequency (KHz) | 5 |
| No. of Controllable Motors | 2 |
| Length (mm): | 40 |
| Width (mm): | 35.5 |
Package Includes:
1 x Mini Motor Drive Shield Expansion Board L293D Module.
