Holybro M9N GPS V2 (IP67)

Holybro M9N GPS V2 (IP67)

Description:

The M9N V2 GPS uses multi-constellation GNSS powered by u-blox M9N, a concurrent GNSS receiver that can receive and track multiple GNSS systems. Owing to the multi-band RF front-end architecture, all four major GNSS constellations, GPS, Galileo, GLONASS, and BeiDou, can be received concurrently.

The V2 design now comes with a more robust casing and an IP67 water&dust resistance rating.
It comes with a built-in IST8310 compass and tricolored LED indicator. There are 2 different connector options for different purposes. This module ships with a baud rate of 115200.

The high-gain 25 x 25 mm patch antenna provides excellent performance, and the omnidirectional antenna radiation pattern increases flexibility for device installation. It features active circuitry for the ceramic patch antenna and a rechargeable backup battery for warm starts.

Feature:

• Ublox M9N or GNSS Receiver
• Accurate Positioning
• Fast Navigation Update Rate
• IST8310 Compass
• High-gain 25*25*4mm antenna
• RGB UI LED controlled by the flight controller
• IP67 water & dust resistance


  ---

Changes From The V1 design

• New casing with IP67 rating
• Added SAW filter and receiver shielding for better signal integrity
• Removed buzzer and safety switch to reduce EM/RF interference
• Removed safety switch LED and GPS Fix LEOnly the RGB UI LED controlled by the flight controller is present for better status recognition


  ---

Specifications :

Note

• This LED is supported in PX4 1.14, ArduPilot 4.4.0 & later. (More info)
• Ardupilot User: If unable to perform normal compass calibration “compass dance” for any reason, set parameter COMPASS_ORIENT=6 (Yaw270) for proper compass orientation.


  ---

PIN MAP

The difference between the two cable options

SKU12089 & 12086 – Holybro M9N GPS (JST GHR1.25mm 10pin cable):

• This option is the most common; it is used on the This connector can be used on Pixhawk Standard Flight Controller 10-pin “GPS Module” or “GPS1” input port.

SKU12090 & 12087 – Holybro M9N Secondary GPS (JST GHR1.25mm 6pin cable):

• This connector can be used on Pixhawk Standard Flight Controller 6-pin“UART & I2C” or “GPS2” input port as a secondary GPS. This GPS is also compatible with the Cube Flight Controller GPS2 Port.


  ---

Package Includes:

• 1x M9N V2 GPS Module
• 1x Fixed Carbon Fiber GPS mount
