Looking for Pin Ic Base? 14 Pin IC Base (DIP) -( Pack of 4) is available at Zbotic with fast shipping across India.
Description:
A 14 pin IC socket base adaptor is a type of IC holder that can be soldered onto the PCB. It allows the IC to be inserted and removed as needed. This is useful for ICs that are sensitive to heat and might get damaged by the soldering iron. It is also helpful for microcontroller ICs that need to be programmed separately.
Features:
- 14 pins
- JDEC compliant
- Molded notch for proper orientation
- Easy to insert and remove ICs
Specifications:
| Current Handling Capacity (A) | 1 |
|---|---|
| No. of Contact Points | 14 |
| Contact Material | Phosphor Bronze |
| Contact Plating | Tin |
| Operating Temperature (°C) | -25 to 85 |
| Flammability Rating | UL94V-0 |
| Color: | Black |
| Insertion Force | 340g max per contact |
| Exertion Force | 80g max per contact |
| Length (mm): | 18 |
| Width (mm): | 10 |
| Height (mm): | 4 |
Package Includes:
- 1 x 14 Pin DIP IC Socket Base Adaptor (4 pcs).
14 Pin IC Base (DIP) – Overview
The 14 Pin IC Base (DIP) pack of 4 is a set of PCB-mountable sockets designed for 14-lead dual in-line package integrated circuits. It provides a reliable interface for inserting and removing ICs without exposing them to soldering heat, ensuring easy replacement and in-circuit programming.
Key Features of 14 Pin IC Base (DIP) –
- 14-pin JDEC-compliant DIP socket for standard dual in-line ICs
- Phosphor bronze contacts with tin plating for corrosion resistance
- Molded orientation notch prevents incorrect IC insertion
- Up to 1 A current handling and –25 °C to 85 °C operating range
- Genuine products sourced from authorized distributors
- Fast shipping across India from Zbotic
Applications and Use Cases
- Prototyping digital logic circuits with removable ICs
- Programming microcontrollers before final soldering
- Swapping out faulty DIP-14 ICs without de-soldering
- Test fixtures and burn-in boards for IC validation
- Educational kits and DIY electronics projects
How to Use 14 Pin IC Base (DIP) –
Solder the 14-pin socket onto your PCB, aligning the molded notch with the PCB silkscreen marking. Once soldered, insert the IC until it seats evenly, and use an IC extractor or flat tool to remove the chip without bending pins.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Can I reuse the 14 Pin IC Base after multiple insertions?
Yes. The phosphor bronze contacts with tin plating maintain spring tension and reliability, allowing repeated insertion and removal of DIP-14 ICs without significant wear.
What current and temperature ranges does this socket support?
The socket supports up to 1 A of current per contact and operates from –25 °C to 85 °C, suitable for most standard PCB applications.
How do I ensure correct orientation when inserting an IC?
Align the molded notch on the socket with the notch marking on your IC and PCB silkscreen. This alignment ensures proper pin-1 positioning and prevents damage from misinsertion.
Technical Specifications
| Pin Count | 14-pin |
|---|---|
| Package Quantity | 4 pcs |
| SKU | AI0619 |
| Weight | 0.0 kg |
| Availability | In Stock |
Applications & Use Cases
The 14 Pin IC Base (DIP) -( Pack of 4) is a versatile ic base used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
Shipping & Delivery
- Free shipping on orders above ₹999 across India
- Dispatched within 1-3 business days
- Expected delivery: 3-7 business days depending on location
- Secure packaging to ensure safe transit of electronic components
