This is the 24V variant of the 1 Channel 24V Relay Module Solid State Low Level SSR DC Control 250V 2A with Resistive Fuse in Solid State Relays, Relays. Available at ₹125.08 (₹106.00 + GST) with free shipping across India.
Looking for 24v Module 460004? 1 Channel 24V Relay Module Solid State Low Level SSR DC Control 250V 2A with Resistive Fuse is available at Zbotic with fast shipping across India.
This 5V 4 Channel SSR Solid State Relay Module 240V 2A Output with Resistive Fuse is based on the Omron G3MB SSR relay which can control up to 2A at 240VAC. This is a 1 Channel SSR relay module, relay channel has 3 separate terminals, NO (Normal Open), COM (Common), NC (Normal Closed).
A sold state relay is similar to a mechanic relay where it can be controlled through a digital signal. sold state relay generates no noise and has a much longer lifespan compared to the traditional mechanic relay.
When the input logic voltage is applied to the coil, the NC will disconnect from the COM breaking the conductivity between the two. At the same time, the NO will connect with the COM allowing conductivity between them. Depending on your wiring this will turn on or off the connected load.
Input parts:
- DC+: connect power positive.
- DC-: connect power negative.
- CH1: relay module signal trigger point (Effective low-level trigger)
Features:
- Has been assembled, and the electrical test passed.
- Led indicator for each relay.
- Use it to control various appliances and other equipment with a large current.
- It can be controlled directly by a Microcontroller.
- Input control signal voltage:
- 0-2.5V status low level, relay OFF.
- 3-5V status high level, relay ON
Specification:
| Part Number | G3MB-202P |
|---|---|
| Power supply | 24VDC/160mA |
| Trigger Voltage (VDC) | 12 |
| Switching Voltage (VAC) | 240@2A |
| Isolation | Phototriac |
| Zero Cross | Yes |
| Shipping Weight | 0.015 kg |
| Shipping Dimensions | 7 × 5 × 1 cm |
Package Includes:
1 x 1 Channel 24V Relay Module Solid State Low Level SSR DC Control 250V 2A with Resistive Fuse
1 Channel 24V Relay Module Solid State Low Level SSR DC Overview
The 1 Channel 24V Relay Module Solid State Low Level SSR DC Control 250V 2A with Resistive Fuse is a single-channel solid state relay board based on the Omron G3MB-202P. It lets you switch AC loads up to 240VAC/2A using a low-level DC control signal while offering phototriac isolation and built-in fuse protection.
Key Features of 1 Channel 24V Relay Module Solid State Low Level SSR DC
- Single SSR channel using Omron G3MB-202P for reliable AC switching
- 5VDC control input draws 160mA with low-level triggering
- Switches up to 240VAC at 2A for lighting, heaters, motors and more
- Phototriac isolation between control and load for noise immunity
- Integrated resistive fuse provides short-circuit and overload protection
- Screw terminals for NO (Normal Open), COM (Common) and NC (Normal Closed)
- Genuine product, fast shipping across India from Zbotic
Applications and Use Cases
- Home automation: silent switching of AC lights and fans
- Industrial control: on/off cycling of pumps and small motors
- Temperature systems: controlling AC heaters in incubators or ovens
- Laboratory equipment: noise-free power control for AC instruments
- Microcontroller projects: integrate with Arduino, Raspberry Pi, PLCs
How to Use 1 Channel 24V Relay Module Solid State Low Level SSR DC
Connect the module’s VCC and GND to a 5VDC supply, then wire your control signal to the IN pin (active low). Hook your AC load between COM and NO for normally-open operation (or COM and NC for normally-closed). Power your AC source into the common terminal and the module will switch the load silently, with the built-in fuse protecting against overloads.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What AC voltage and current can this module handle?
This SSR module can switch AC loads up to 240VAC at a maximum current of 2A, suitable for lighting, small motors and resistive heaters.
What control signal voltage is required?
The module requires a 5VDC control input with a typical current draw of 160mA. The input is active low, making it compatible with most microcontrollers and TTL logic.
Does the module include overcurrent protection?
Yes, it features a built-in resistive fuse that safeguards both the relay and the connected load against short circuits and overload conditions.
