XL6009 LM2596 DC-DC Step Up Down Boost Buck Voltage Power Converter Module
XL6009 LM2596 DC-DC Step Up Down Boost Buck Voltage Power Converter Module is a non-isolated Step up and step down ( boost as well as buck) constant voltage (CV) DC-DC converter Module. The main advantage of using this module is the output voltage remains fixed even if the input voltage goes below or above the set voltage. This module has Output voltage independent of input voltage (3.5V-28V input, any value output 1.25V-26V).
In this you can set the output voltage anywhere from 1.25 volts to 26 volts and even if the input voltage varies from 3.5 volts to 28 volts the output voltage will remain fixed as per the set voltage (which can be adjusted using on-board trim pot).
This module is perfect for solar application where you want to give constant 12 to 14 volts to charge your battery but the the output of the solar panel varies according to the sunlight.
Package Includes:
- 1 x XL6009 LM2596 DC-DC Step Up Down Boost Buck Voltage Power Converter Module
XL6009 LM2596 DC-DC Step Up Down Boost Buck Voltage Power Overview
The XL6009 LM2596 module is a non-isolated DC-DC converter that combines boost (step-up) and buck (step-down) regulation in one board. It accepts an input range of 3.5–28 V and provides a stable, adjustable output from 1.25–26 V, making it ideal for custom power supply applications.
Key Features of XL6009 LM2596 DC-DC Step Up Down Boost Buck Voltage Power
- Wide input voltage range: DC 3.5 V to 28 V for versatility with batteries and adapters
- Adjustable output: 1.25 V to 26 V via onboard potentiometer
- Stable constant-voltage output independent of input fluctuations
- Maximum input/output current up to 3 A; continuous rated current of 1 A
- Compact PCB design with mounting holes for easy integration
- Genuine product with fast shipping across India from Zbotic
Applications and Use Cases
- Custom bench power supplies for electronics prototyping
- Regulating voltage for LED strips, lighting projects, and displays
- Down-converting automotive 12 V or 24 V to lower levels for sensors
- Boosting handheld battery outputs to run higher-voltage modules
- Solar panel voltage regulation for small off-grid setups
- Portable charger circuits where adjustable output is required
How to Use XL6009 LM2596 DC-DC Step Up Down Boost Buck Voltage Power
Wire the input terminals to your DC source (3.5–28 V) and connect your load to the output terminals. Use a multimeter on the output while turning the onboard potentiometer to set the desired voltage between 1.25 V and 26 V. For currents approaching 3 A, mount a small heatsink on the XL6009 chip to ensure stable operation.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Can this module both boost and buck voltage?
Yes. The XL6009 LM2596 board automatically switches between boost (step-up) and buck (step-down) modes, keeping your output voltage constant even if the input goes above or below the set level.
How do I adjust the output voltage?
Connect a multimeter to the output terminals, power the module, and turn the blue potentiometer screw slowly until the multimeter reads your desired voltage within the 1.25 V–26 V range.
What current can I safely draw without additional cooling?
The board’s continuous rated current is 1 A, but it can handle up to 3 A intermittently. For sustained currents above 1 A, attach a heatsink to the XL6009 chip to prevent thermal shutdown.
Technical Specifications
| Model | XL6009 |
|---|---|
| SKU | AI1107 |
| Weight | 0.05 kg |
| Availability | Out of Stock |
Applications & Use Cases
The XL6009 LM2596 DC-DC Step Up Down Boost Buck Voltage Power Converter Module is a versatile buck converter used across a wide range of applications including voltage step-down for electronics, battery-powered projects, LED driver circuits, microcontroller power supply, and solar power regulation.
Common use cases:
- Converting 12V car battery to 5V for USB devices
- Powering a Raspberry Pi from a drone battery
- Regulating solar panel output for charging
This product is ideal for electronics hobbyists, IoT developers, and power supply designers.
Technical Tip: Buck converters are more efficient than linear regulators (LM7805). Choose one rated for at least 1.5x your required current. Ensure input voltage is at least 2V above output.
