Product Description
The Bluetooth XBee Shield V03 Module Wireless Control is a device that enables wireless communication between Arduino boards using the ZigBee protocol and the XBee module. It supports all types of XBee modules, including Series 1 and Series 2 (and 2.5), standard and Pro versions.
This shield comes fully assembled, except for the XBee module itself. You need to attach an XBee module to the shield before using it.
The XBee Shield makes it easy to connect an XBee with your Arduino. It fits directly on top of an Arduino Pro or USB board, and gives it wireless capabilities with the popular XBee module.
.
Applications :
- PC via a USB cable directly connected with XBee adapters.
- Bluetooth Bee configures or uses as a data-transmission.
- Arduino board pro mini downloader.
Features :
- Stackable design, easy to plug into the ARDUINO development board.
- Coupled with the Arduino Bluetooth Bee Bluetooth module, and other Bluetooth devices can communicate Wirelessly.
- Coupled with the XBee module, you can achieve two or more sets of communication between Arduino or Arduino and PC Communications.
- 3.3v and 5v dual power output.
- 3.3v and 5v IO compatible.
- USB 2.0 protocol.
- Bitbang mode ready.
- Easily connected to a PC via mini USB Cable.
- XBee-setting support software X-CTU.
Package Includes :
1 x Bluetooth XBee Shield V03 Module Wireless Control.
XBee Shield V03 Module Wireless Control Overview
The XBee Shield V03 Module Wireless Control is a stackable expansion board designed to plug directly into Arduino development boards. It enables wireless communication using XBee modules (Series 1, 2, 2.5, standard and Pro) or Bluetooth Bee modules, offering flexible 3.3 V/5 V power and I/O compatibility.
Key Features of XBee Shield V03 Module Wireless Control
- Stackable design for seamless plug-in on Arduino Pro, Uno or USB boards
- Compatible with all XBee modules: Series 1, Series 2/2.5 and Pro variants
- Dual power output: selectable 3.3 V or 5 V, with matching 3.3 V/5 V I/O levels
- USB 2.0 protocol support for PC configuration via XBee adapters
- Works with Bluetooth Bee for Bluetooth-based wireless links
- Fast shipping from Zbotic: orders dispatched within 24 hours
Applications and Use Cases
- Point-to-point wireless serial links between Arduino boards
- Mesh network setups for environmental sensing or home automation
- Remote robot control and telemetry over ZigBee or Bluetooth
- PC-to-Arduino data exchange via USB XBee adapter and XCTU
- Wireless logging of sensor data in industrial or academic projects
- Prototyping IoT projects with low-power wireless modules
How to Use XBee Shield V03 Module Wireless Control
To get started, mount the XBee Shield V03 onto your Arduino board and insert the chosen XBee or Bluetooth Bee module into the socket. Set the voltage jumper for 3.3 V or 5 V operation, then connect a USB–XBee adapter if configuring via PC. Upload your Arduino sketch for serial communication, power on the setup, and pair or network your modules using XCTU or AT commands.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Which XBee modules can I use with this shield?
The XBee Shield V03 supports all Series 1 and Series 2/2.5 XBee modules, including both standard and Pro versions. You can also use Bluetooth Bee modules for Bluetooth communication.
How do I switch between 3.3 V and 5 V operation?
There is a voltage selection jumper on the shield. Place it in the 3.3 V position for low-voltage modules or in the 5 V position for 5 V logic. Ensure the Arduino board is set to the same voltage level.
Can I configure the XBee module via my PC?
Yes. Use a USB–XBee adapter connected to your PC and run Digi’s XCTU software. This lets you read and write module settings, test range, and establish network parameters.
