This is the Red variant of the Unsoldered Nano V3.0 ATmega328P 5V 16MHz CH340 Type-C in Boards Compatible with Arduino. Available at ₹208.86 (₹177.00 + GST) with free shipping across India.
PRODUCT DESCRIPTION
This microcontroller board is based on the ATmega328 MCU and is called the Unsoldered Nano V3.0 ATmega328P 5V 16MHz CH340 Type-C. It is similar to the Arduino Duemilanove in terms of functionality, but it is smaller in size. It does not have a DC power jack and it uses a Mini USB (Mini-B) connector instead of a standard USB connector.
You can program this board with Arduino programs and the Arduino IDE. This board uses the CH340G USB interface controller.
You can power this board in three ways: through the Mini-B USB connection, a 6-20V unregulated external power supply (pin 30), or a 5V regulated external power supply (pin 27). The board automatically selects the highest voltage source as the power source.
Features:
- CH340G USB bus converter chip replaces FT232RL
- Operating Voltage(logic level): 5V
- 8 analog inputs ports: A0 – A7
- 14 Digital input/output ports: TX, RX, D2 – D13
- 6 PWM ports: D3, D5, D6, D9, D10, D11
- 1 pair of TTL level serial transceiver ports: RX / TX
- Uses Atmel Atmega328P-AU MCU with bootloader installed
- Support USB download and Power over Mini-B Mini USB connector
- Recommended input voltage: 7V – 12V DC on pin 30 or 5V on pin 27
- Maximum input voltage limits: 6V – 20V
- Supports ISP download
- Supplied with connector pins (headers), not soldered to the board for user flexibility
Specification:
| 8 analog inputs ports | A0 – A7 |
|---|---|
| 14 Digital input/output ports | TX, RX, D2 – D13 |
| 6 PWM ports | D3, D5, D6, D9, D10, D11 |
| 1 pair of TTL level serial transceiver ports | RX / TX |
| Support USB download and Power over USB Type-C connector | Yes |
| Recommended input voltage | 7V – 12V DC on pin 30 or 5V on pin 27 |
| Maximum input voltage limits | 6V – 20V |
| Supports ISP download | Yes |
| Supplied with connector pins (headers), not soldered to the board for user flexibility | Yes |
| Shipping Weight | 0.021 kg |
| Shipping Dimensions | 10 × 9 × 1 cm |
Package Includes:
- 1 X Nano V3.0 16MHz CH340
