PRODUCT DESCRIPTION
The ME-8166 Rotary Adjustable Roller Mini Limit Switch, often known as the POSITION SWITCH, is a frequently used electrical device for small current applications. It interacts with the moving parts of production machinery or a control circuit via contact, achieving a designated control function.
This Limit Switch is ideal for use as an electrical control switch in mechanical and various industrial settings. It can track the positions of moving parts in machinery and equipment. Before utilizing the Limit Switch, verifying the Voltage Rating for compatibility with your local voltage is crucial.
Features:
- The actuator is activated only when pressed. It has a rotary lever arm with a roller that can be adjusted. It has two normally closed and two normally open contacts. It is dust-tight and water-resistant with an IP rating of 66.
Specifications:
- Model: ME-8166
- Voltage Rating: AC380V, 6(2)A, AC250V, 10(4)A
- Actuator action: Momentary
- Material: Resin, Plastic, Metal
- Roller Dimension: 1.8 x 0.7cm
- Body Dimension: ~88 x 28 x 25mm
- IP Rating: IP66
- Weight (gm): 60
Package Includes:
1 x ME-8166 Rotary Adjustable Roller Mini Limit Switch.
ME-8166 Rotary Adjustable Roller Mini Limit Switch. Overview
The ME-8166 is a compact rotary adjustable roller limit switch designed for precise position detection in small-current control circuits. Featuring a momentary actuator with an adjustable roller lever, it ensures reliable contact operation in industrial machinery and automation systems.
Key Features of ME-8166 Rotary Adjustable Roller Mini Limit Switch.
- Rotary lever arm with 1.8 cm × 0.7 cm adjustable roller for accurate actuation.
- Momentary actuator action: contact closes only while the roller is pressed.
- Voltage ratings: 6 (2) A at AC 380 V and 10 (4) A at AC 250 V for versatile applications.
- Dual contact outputs: two normally closed (NC) and two normally open (NO) circuits.
- Durable metal, plastic, and resin construction in a compact 88 mm × 28 mm × 25 mm body.
- Genuine product with fast shipping from Zbotic—get it on your bench quickly.
Applications and Use Cases
- End-of-travel detection on conveyor and assembly lines.
- Position feedback for robotic arms and pick-and-place stations.
- Limit control in CNC machines, packaging equipment, and presses.
- Safety interlocks on automated doors and guarding systems.
- Home-made industrial prototypes requiring precise motion cut-off.
- Triggering alarms or indicators when a moving part reaches a set point.
How to Use ME-8166 Rotary Adjustable Roller Mini Limit Switch.
Mount the switch securely to your machine’s frame, align the roller arm to the moving part’s travel path, then tighten the adjustment screw. Wire the NC/NO terminals per your control diagram, verify the AC380 V/AC250 V rating matches your system, and test actuation by manually pressing the roller to confirm reliable switching.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What is the maximum switching current of the ME-8166?
The switch can handle up to 6 A (2 A inductive) at AC 380 V and up to 10 A (4 A inductive) at AC 250 V, making it suitable for small-current control circuits.
How do I adjust the roller lever angle?
Loosen the small retaining screw on the lever arm, rotate the roller to the desired position, then re-tighten the screw. This allows fine-tuning of actuation points along your machine’s moving part.
Can the ME-8166 be mounted in any orientation?
Yes. The robust metal and resin body supports horizontal, vertical, or inverted mounting. Ensure the roller engages the moving part smoothly without binding.
Technical Specifications
| Model | ME-8166 |
|---|---|
| Interface / Protocol | BLE |
| SKU | AI3315 |
| Weight | 0.07475 kg |
| Availability | In Stock |
