This is the 6V variant of the LM7806 6V DC / AC, Three Terminal Voltage, Regulator Power in Buck Converter. Available at Original price was: ₹107.38.₹88.50Current price is: ₹88.50. (₹75.00 + GST) with free shipping across India.
LM7806 6V DC / AC, Three Terminal Voltage, Regulator Power
L7806 module integrated rectifier, filter element, and voltage regulator, an input AC or DC voltage, and output stabilized DC6V voltage, have overheated and over current protection function.
Features:
- Overheat protection, overcurrent protection.
specification
| Input Voltage (V) | 9-24 |
|---|---|
| Max Output Current (mA) | 1200 |
| Output Voltage(V) | 6 |
| Shipping Weight | 0.03 kg |
| Shipping Dimensions | 6 × 4 × 1 cm |
Package Includes:
1 x LM7806 6V DC / AC, Three Terminal Voltage, Regulator Power
LM7806 6V DC / AC, Three Terminal Voltage, Regulator Power Overview
The LM7806 is a three-terminal voltage regulator module that accepts 9–24V AC or DC input and delivers a stable 6V DC output at up to 1.2A. It integrates rectifier, filter elements, and protection circuitry, making it ideal for powering electronics requiring a reliable 6V supply.
Key Features of LM7806 6V DC / AC, Three Terminal Voltage, Regulator Power
- Wide input range: 9–24V DC or AC compatible
- Stable 6V DC output with maximum 1.2A current capacity
- Built-in rectifier and filter for clean, ripple-free output
- Overheat and overcurrent protection for safe operation
- Compact three-terminal design for easy PCB or chassis mounting
- Genuine product with fast shipping from Zbotic
Applications and Use Cases
- Powering 6V LED strips and indicator lights in DIY projects
- Supplying stable voltage to microcontroller and logic circuits
- Charging or powering 6V battery packs in portable devices
- Driving 6V motors, servos, and actuators in robotics kits
- Creating custom bench power supplies for electronics testing
How to Use LM7806 6V DC / AC, Three Terminal Voltage, Regulator Power
Mount the module securely on your chassis or PCB, then connect the 9–24V AC or DC source to the input terminals, observing polarity for DC. Tie the ground terminal to your circuit’s common ground. The regulator will automatically rectify (if AC), filter, and output a steady 6V DC. Attach a suitable heat sink if you anticipate currents near 1.2A to maintain optimal temperature.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Can the LM7806 accept AC input directly?
Yes. The module includes an integrated bridge rectifier and filter capacitors, so you can feed it 9–24V AC directly and still obtain a regulated 6V DC output.
Do I need a heat sink when drawing 1.2A?
For continuous currents approaching 1.2A, a heat sink is recommended. Proper thermal management ensures the regulator stays within safe operating temperatures and prolongs its lifespan.
How should I wire the LM7806 for a DC power source?
Connect your DC supply’s positive to the VIN terminal, negative to the GND terminal, and take the regulated 6V from the VOUT terminal. Ensure correct polarity to avoid damage.
Technical Specifications
| Model | LM7806 |
|---|---|
| Operating Voltage | 6V |
| SKU | AI2524 |
| Weight | 0.0208 kg |
| Availability | In Stock |
