Axisflying Argus H743 Pro 6-12S Flight Controller – Dual ICM42688P Gyro
Description:
Feature:
- Flagship STM32H743 main controller, clock speed up to 480MHz for strong computing performance
- Dual ICM42688P gyros with external clock sync and independent power supply for ultra‑stable data
- High‑precision DPS368 barometer for accurate altitude hold and stable hovering
- Dual BEC output: 5V/2.5A + 12V/2A for stable power supply to peripherals
- 7 UART ports for rich expansion (receiver, GPS, VTX, HD system, etc.)
- Onboard OSD, 16M Blackbox, and current sensor supported
- Plug‑and‑play design, no soldering required for most connections
- Standard 30.5×30.5mm mounting holes for universal stack compatibility
- Ultra‑light weight at only 9g
Recommended Configuration
- Model: Axisflying H743 PRO Flight Controller
- Input Voltage: 4–8S LiPo /12S
- Mount: 30.5×30.5mm / M3
- Application: 5–10 inch freestyle, long‑range, heavy‑load and cinematic FPV drones
Specifications
| Specification | Value |
|---|---|
| Main Controller | STM32H743 |
| Gyroscope | Dual ICM42688P |
| Barometer | DPS368 |
| OSD | Supported |
| Blackbox | 16MB Flash Memory |
| Input Voltage | 4–8S LiPo / 12S |
| BEC Output | 5V / 2.5A, 12V / 2A |
| UART Ports | 7 |
| Motor Outputs | M1–M8 (8 Motors Supported) |
| USB Interface | USB Type-C |
| LED & Buzzer | Supported |
| Current Sensor | Supported |
| Mounting Hole | 30.5 × 30.5 mm / M3 |
| Dimensions | 38 × 38 × 8 mm |
US Tariff Information
- Tariff: 3.7% + Section 301 additional duty (as of May 2026)
- Type 86 ($800 duty‑free) is terminated; all commercial shipments are dutiable.
Package Include:
- 1x AXISFLYING H743 PRO Flight Controller
- 1x User Manual
- 4x M3 Silicone Damping Column
- 4x Nylon Nut
- 4x Button Head Socket Cap Screw
- 1x 10P Silicone Wire
- 1x 8P Silicone Wire
- 2x 4P Silicone Wire
- 1x GPS Custom Cable
- 1x Packaging Box
