Adafruit MS8607 Pressure Humidity Temperature PHT Sensor – STEMMA QT / QwiicRoHS Compliant

Because of their many applications, Pressure, Temperature, and Humidity sensors (PHT sensors) are a common offering from semiconductor companies. The MS8607 PHT sensor from TE Connectivity does an admirable job of measuring a wide range of all three environmental conditions. Each and every MS8607 sensor is calibrated at the factory and the calibration constants stored in the sensor itself. This sensor is a one-stop-shop for all your common weather and environmental-related metrics. Just add an MS8607 and you’ll be ready to finish your enclosure and retire as a Dubia Cockroach Farmer

One standout feature of the MS8607 is it’s very respectable low power consumption at as low as 0.78 µA ! That’s hardly anything! Along with carefully managed microcontroller power usage, getting good battery life out of your sensing project will be that much easier.

While the MS8607 sensor itself is rotund by comparison to some of the other sensors we stock, it’s still a surface mount part so we’ve placed it on a breakout board, nestled amongst a handful of components that take care of level shifting and power regulation. This lets you use it with either 5V or 3.3V devices, so no matter if you have an Arduino, Metro, Feather, or Raspberry Pi, you’ll be able to interface with the MS8607 easily. The breakout has the expected header for power and I2C connections, however, if you prefer to or can’t solder, you can use the Spark Fun Qwiic compatible STEMMA QT connectors to wire up to your favorite micro with a  plug-and-play cable. Even if like me you don’t mind soldering, STEMMA QT connectors are super convenient for wiring up projects quickly. QT Cable is not included, but we have a variety in the shop.

Features:

1. The MS8607 provides the previously mentioned factory-calibrated pressure
2. Humidity data are recorded as 16-bit values and made available over an I2C bus for simple
3.  Pressure measurements accuracy comes in at +/- 2 hPa
4. Relative humidity at +/- 3% rH
5. temperature is good to within 1 degree Celsius
6. The MS8607 is it’s very respectable low power consumption

Packages Includes:

1 x Adafruit MS8607 Pressure Humidity Temperature PHT Sensor – STEMMA QT / QwiicRoHS Compliant

Datasheet:

Adafruit MS8607 Pressure Humidity Temperature PHT Sensor Overview

The Adafruit MS8607 Pressure Humidity Temperature PHT Sensor is a compact, factory-calibrated triple sensor module for measuring barometric pressure, relative humidity, and ambient temperature. It features a STEMMA QT/Qwiic connector and I²C logic, making it ideal for rapid integration into weather stations, environmental monitors, or battery-powered data loggers.

Key Features of Adafruit MS8607 Pressure Humidity Temperature PHT Sensor

• Factory-calibrated MS8607 chip from TE Connectivity for reliable pressure, humidity, and temperature readings
• 16-bit humidity resolution with internal calibration constants stored on-chip
• Operates at 3.3 V or 5 V with standard I²C logic pins
• STEMMA QT and Qwiic compatible connectors for solderless plug-and-play use
• Ultra-low power sleep current as low as 0.78 µA, ideal for battery-powered projects
• RoHS-compliant black PCB with minimal footprint
• Fast shipping from Zbotic.in across India

Applications and Use Cases

• Home or rooftop weather stations measuring barometric trends
• Greenhouse humidity and temperature control systems
• Portable environmental data loggers and IoT prototypes
• HVAC monitoring and air-quality feedback loops
• Wearable or handheld instruments for field research
• Battery-powered agricultural monitoring setups

How to Use Adafruit MS8607 Pressure Humidity Temperature PHT Sensor

Simply connect the sensor’s STEMMA QT or Qwiic cable to your microcontroller’s I²C pins (SDA, SCL), and apply 3.3 V or 5 V power to VCC and GND. Install the Adafruit MS8607 library in your Arduino IDE or CircuitPython environment, call the initialization routine, then read pressure, humidity, and temperature values via the provided APIs.

Why Buy from Zbotic?

• Genuine Products: All items sourced from authorized distributors
• Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
• Free Shipping: Free delivery on qualifying orders
• COD Available: Cash on Delivery, UPI, cards, net banking
• Technical Support: Expert help for setup and troubleshooting
• Easy Returns: Hassle-free replacement for defective products

Frequently Asked Questions

What voltage levels does the Adafruit MS8607 support?

The MS8607 module accepts both 3.3 V and 5 V on its VCC pin and uses I²C logic levels that match your microcontroller, making it compatible with most Arduino, Raspberry Pi, and other development boards.

How do I interface the MS8607 with an Arduino?

Use the STEMMA QT or Qwiic connector to link SDA and SCL to your Arduino’s I²C pins, then install the Adafruit MS8607 library via the Library Manager. Initialize the sensor in your sketch and call the read routines to retrieve pressure (hPa), humidity (%RH), and temperature (°C).

What is the power consumption of the MS8607 when idle?

In its lowest-power sleep mode, the MS8607 draws as little as 0.78 µA. Active measurement currents are higher but optimized for efficient battery operation, making it suitable for long-term data logging.
