6 Channel 3-24V Relay Module Solid State Low Level SSR DC Control DC with Resistive Fuse
Upgrade your control system with the 5V 6-Channel SSR Solid State Relay Module, featuring the reliable Omron H3MB-052D SSR relay capable of controlling up to 2A at 240VAC. This module provides seamless switching functionality for various applications while offering enhanced durability and noise-free operation.
Features:
- Omron H3MB-052D SSR Relay: Delivers efficient control of up to 2A at 240VAC, ensuring reliable switching performance.
- 6-Channel Configuration: Control up to 6 independent loads with ease, offering versatility in your projects.
- Solid State Relay Technology: Enjoy noise-free operation and extended lifespan compared to traditional mechanical relays, enhancing overall reliability.
- Separate Terminals for Each Channel: Each relay channel features three separate terminals: NO (Normal Open), COM (Common), and NC (Normal Closed), allowing for flexible wiring configurations.
- Input Control Signal Voltage: Accepts input control signal voltage ranging from 0 to 5V, with 0-2.5V indicating a low level (relay OFF) and 3-5V indicating a high level (relay ON), ensuring compatibility with various control systems.
- LED Indicator: Equipped with LED indicators for each relay, providing convenient status monitoring.
- Assembled and Electrically Tested: Each module is assembled and subjected to electrical testing to ensure optimal performance and reliability.
- Microcontroller Compatibility: Can be easily controlled directly by a microcontroller, simplifying integration into your control setup.
- Resistive Fuse: Includes a resistive fuse for added safety and protection against overcurrent conditions.
- Wide Range of Applications: Suitable for controlling various appliances and equipment requiring large current switching, offering versatility in usage scenarios.
Input Parts:
- DC+: Connects to power positive for the supply voltage.
- DC-: Connects to power negative for the ground connection.
- CH1-CH6: Individual relay module signal trigger points with effective low-level triggering, enabling precise control over each channel.
Enhance your control capabilities with the 5V 6-Channel SSR Solid State Relay Module, designed to deliver reliable performance, ease of use, and flexibility for a variety of applications. Whether you’re controlling appliances, equipment, or other devices, this module provides a robust solution for your switching needs.
Specifications:
| Part Number | H3MB-052D |
|---|---|
| Working current(mA) | 12.5 |
| Trigger Current (mA) | 2 |
| Trigger Voltage (VDC) | 3-24 |
| Switching Voltage (VDC) | 50@2A |
| Max. Load | 2A @50V AC |
| Shipping Weight | 0.051 kg |
| Shipping Dimensions | 13 × 6 × 3 cm |
Package Includes:
1 x 6 Channel 3-24V Relay Module Solid State Low-Level SSR DC Control DC with Resistive Fuse
6 Channel 3-24V Relay Module Solid State Low Level SSR DC Overview
The 6 Channel 3-24V Relay Module Solid State Low Level SSR DC Control DC with Resistive Fuse features six independent Omron H3MB-052D solid state relays with built-in resistive fuses. Designed for noiseless, reliable switching of AC or DC loads up to 2 A, it’s ideal for industrial automation, home control panels or any application requiring clean, long-life relay operation.
Key Features of 6 Channel 3-24V Relay Module Solid State Low Level SSR DC
- Omron H3MB-052D Relays: Each channel handles up to 2 A at 240 VAC for robust load switching.
- Wide Control Range: Low-level DC trigger from 3–24 V with only 2 mA input current per channel.
- Built-In Resistive Fuses: One fuse per channel protects against overcurrent and simplifies maintenance.
- Solid State Design: No mechanical contacts for silent operation, fast switching and extended lifespan.
- Compact Six-Channel Layout: Space-saving board that consolidates multiple relay outputs.
- Fast Shipping from Zbotic: Genuine modules dispatched across India within 24 hours.
Applications and Use Cases
- Home automation: switching lights, fans or small appliances
- Industrial control: PLC interfaces and factory automation panels
- Signal isolation: separation of microcontroller outputs from high-voltage lines
- Heating element control: precise on/off switching of resistive loads
- Automated test setups: cycling power to devices under test
How to Use 6 Channel 3-24V Relay Module Solid State Low Level SSR DC
Connect the module’s VCC and GND to a 3–24 V DC supply. Wire each control input through your microcontroller or logic circuit, pulling it low (<1 V) to activate the corresponding SSR and switch the load line connected to the relay output terminals. Ensure loads do not exceed 2 A and inspect the resistive fuse holders periodically—replace fuses if tripped.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What voltage range triggers the SSR inputs?
The module accepts a DC control voltage between 3 V and 24 V. Driving an input pin low (below ~1 V) activates its SSR channel; pulling it high (3–24 V) turns the channel off.
Can I switch both AC and DC loads with this relay module?
Yes. Each Omron H3MB-052D SSR channel can handle up to 2 A at 240 VAC for AC loads and up to 50 V DC for DC loads. Always ensure your load stays within these ratings.
How do I replace a blown resistive fuse on a channel?
Locate the small resistive fuse holder next to the affected SSR channel, pull out the blown fuse, and insert a matching value replacement fuse to restore overcurrent protection.
