This is the 5V variant of the 5V 8 Channels Relay Module High and Low, Triggering Optocoupler, Isolation Relay Module, PLC Signal Amplifier, Board in Relay Modules. Available at ₹1,508.04 (₹1,278.00 + GST) with free shipping across India.
PRODUCT DESCRIPTION
This module is an 8-channel 5V relay control board featuring optocoupler isolation. It complies with international safety standards and includes isolation trenches between the control and load sections, ensuring reliable performance from high-quality relays.
The inputs of the 8-Channel 5V Relay Module are isolated to protect sensitive control circuitry. It includes indicators for power supply and relay status: when the input signal is active, the common terminal connects to the signal terminal. This module can handle both DC and AC loads up to 220V AC.
Compatible with various microcontrollers such as Arduino, AVR, PIC, and ARM, the module also features a guide rail on the backside for easy mounting in a suitable location.
Note: On the high level and low level-triggered mode, friends who do not understand, have a look
High-level trigger refers to the signal voltage between input and trigger, can be understood as a signal input with VCC cathode short-circuit triggered away;
Low-level trigger refers to the signal voltage between the input terminal and Earth OV trigger, can be understood as a signal input terminal and the GND negative electrode short circuit triggered is a way 8-channel relay module connection.
Features:
High impedance controller pin
Pull-down circuit for the avoidance of malfunction
One normally closed contact and one normally open contact
Triode drive, increasing relay coil
Specifications:
Trigger Voltage
5
Switching Voltage (VAC)
250@30A
Switching Voltage
30@30A
Shipping Weight
0.149 kg
Shipping Dimensions
20 × 11 × 1 cm
Package Includes:
1 x 5V 8 Channels Relay Module High and Low Triggering Optocoupler Isolation Relay Module PLC Signal Amplifier Board
5V 8 Channels Relay Module High and Low, Triggering Overview
The 5V 8 Channels Relay Module High and Low, Triggering is an 8-channel control board designed to switch high-power AC or DC loads using 5V logic signals. With optocoupler isolation and selectable high-level or low-level triggering, it ensures safe interfacing between microcontrollers and devices up to 250VAC/30A or 30VDC/30A.
Key Features of 5V 8 Channels Relay Module High and Low, Triggering
8 independent 5V relay channels with both normally open (NO) and normally closed (NC) contacts
Optocoupler isolation and PCB trenches separate control and load sections for noise immunity
Selectable high-level or low-level trigger per channel via onboard jumper
Switching capacity up to 250VAC/30A and 30VDC/30A for AC and DC loads
LED indicators for power status and individual relay activation
Backside guide-rail mounting for easy installation in panels or enclosures
Compatible with Arduino, AVR, PIC, ARM and other 5V microcontrollers
Genuine product, fast shipping from Zbotic
Applications and Use Cases
Home automation: control lighting, fans and pumps from microcontrollers
Industrial PLC signal amplification for driving motors and solenoid valves
Security systems: activate sirens, alarms or door locks
Prototyping relay banks for AC mains or DC power control
Automated test benches switching resistive and inductive loads
How to Use 5V 8 Channels Relay Module High and Low, Triggering
Begin by supplying 5V and GND to the VCC and GND pins, then set each channel’s trigger mode (high-level or low-level) via the onboard jumper block. Connect your microcontroller digital outputs to the eight IN pins, and wire your load devices between the COM, NO, or NC terminals. Power on the module, send a logic HIGH or LOW as configured, and observe the corresponding LED lighting as each relay switches your AC or DC load.
Why Buy from Zbotic?
Genuine Products: All items sourced from authorized distributors
Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
Free Shipping: Free delivery on qualifying orders
COD Available: Cash on Delivery, UPI, cards, net banking
Technical Support: Expert help for setup and troubleshooting
Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Can this module switch both AC and DC loads?
Yes. Each relay channel can handle up to 250VAC at 30A or 30 at 30A, making it suitable for both mains AC applications and high-current DC circuits.
How do I select high-level or low-level triggering?
Use the onboard jumper header labeled “JD-VCC” to configure trigger mode. Place the jumper to enable high-level trigger (active at 5V) or remove it for low-level trigger (active at 0V).
How do I mount this relay module securely?
The module features a guide-rail clip on the backside, allowing easy DIN-rail or panel mounting in your control cabinet without additional brackets.
The 5V 8 Channels Relay Module High and Low, Triggering Optocoupler, Isolation Relay Module, PLC Signal Amplifier, Board is a versatile relay modules used across a wide range of applications including home automation, industrial control, IoT projects, Arduino/Raspberry Pi interfacing, and motor control.
Common use cases:
Switching high-voltage AC appliances with a microcontroller
Building a smart home relay board
Automating irrigation pumps in agriculture
This product is ideal for electronics engineers, IoT developers, and automation hobbyists.
Technical Tip: Use optocoupler-isolated relay modules to protect your microcontroller. Match relay coil voltage to your MCU logic level (3.3V or 5V).
