5V 1 Channel Bluetooth, Relay Module Things, Smart Home Remote, Control Switch
Elevate your project’s control capabilities with the Single Channel Bluetooth Wireless Relay Module, designed to effortlessly activate devices operating at up to 250V AC and 30V DC. This versatile module enables remote control of lights, systems, and more, making it ideal for a variety of applications.
Features:
- Bluetooth Connectivity: Equipped with an onboard Bluetooth chipset, this module enables seamless relay triggering via Bluetooth signals. Simply pair the module with your Bluetooth-enabled device, such as a mobile phone, to gain control.
- LED Indicators: Features two onboard LEDs for easy status monitoring. The blue LED indicates Bluetooth state, blinking slowly during search and remaining steady when the connection is established. The red LED serves as the relay indicator, displaying the ON-OFF status of the relay.
- Audible Feedback: Provides audible feedback with a click sound when the relay triggers, connecting the output pins.
- Install Android APP: Begin by installing the Android APP required for Bluetooth control.
- Pairing: Search for the Bluetooth device on your mobile phone and connect to it. The pairing password is “1234”.
- Sending Commands: Input the name and content of the instruction, such as the open relay instruction “A00101A2” and close relay instruction “A00100A1”, in hexadecimal form. Select “send” to transmit the commands.
- Operating Voltage: The module operates at 5VDC, providing compatibility with various power sources.
- Relay Rating: Features an onboard 5V relay capable of handling 10A at 250V AC or 30V DC, with a lifespan of up to 100,000 continuous switching cycles.
- Optocoupler Isolation: Enhanced with 4 optocoupler isolations for robust anti-interference capabilities, ensuring reliable performance in diverse environments.
- Bluetooth Module: Utilizes an onboard N76E003/STM8S003 microcontroller and SPP-C Bluetooth 2.1 module for efficient communication and control.
- Effective Control Distance: Offers an effective control distance of up to 10m in open areas, providing flexibility in usage.
- Compact Design: Designed with compact dimensions (63 x 23 x 19mm) and lightweight construction (20g) for easy integration into your project.
Enhance your project’s control and automation capabilities with the Single Channel Bluetooth Wireless Relay Module, offering seamless Bluetooth control, robust relay performance, and easy integration. Whether you’re controlling lights, systems, or appliances, this module provides a convenient and efficient solution for wireless relay contro.
Specifications:
| Onboard | N76E003/STM8S003 and SPP-C Bluetooth 2.1 module |
|---|---|
| Module Operating Voltage | 5VDC |
| Effective control distance(on open area) | 10m |
| Board Dimensions (mm) | 63 x 23 x 19 |
| Weight (g): | 20 |
| Shipping Weight | 0.03 kg |
| Shipping Dimensions | 6 × 3 × 2 cm |
Package Includes:
1 x DC 5V 1 Channel Bluetooth Wireless Control Relay Module
Note: The Images shown may vary from the actual product in terms of design, according to availability from the manufacturer
