This is the 12V variant of the 4 Road/Channel Relay Module 12V (with light coupling) in Relay Modules. Available at Original price was: ₹173.46.₹158.12Current price is: ₹158.12. (₹134.00 + GST) with free shipping across India.
Description:
This 4-Channel Relay Module (with optical coupling) operates at 12V and adheres to safety standards, featuring an isolation groove between the control area and the load area for enhanced protection. The optical coupling ensures reliable and stable triggering of the relays.
The module boasts a double FR-4 circuit board design and high-quality SMT processing. It includes indicators for power and relay operation, while the relay terminals (C, NC, NO) are easily accessible via screw terminals, simplifying the wiring process.
The inputs of the 4-Channel 12V Relay Module are isolated to safeguard sensitive control circuitry. It is compatible with a wide range of microcontrollers, including Arduino, AVR, PIC, and ARM.
Using high-voltage relays minimizes the risk of overheating, as electromechanical relays regulate current consumption based on their voltage rating.
Module Interface:
- VCC: Connect power supply (positive according to relay voltage)
- GND: Connect power negative
- IN1: Relay module (effective) high-level trigger signal trigger end
- IN2: Relay module (effective) high-level trigger signal trigger end
- IN3: Relay module (effective) high-level trigger signal trigger end
- IN4: Relay module (effective) high-level trigger signal trigger end
Meaning of High Level and Low Level:
- High-level trigger: Refers to using the anode voltage at the VCC connection way of a trigger and triggers the end when the trigger side has the positive voltage or to trigger voltage when the relay is off.
- Low-level trigger: Refers to using the negative voltage at the GND connection way of a trigger and triggers the end when the trigger side has 0 V low voltage or voltage to can trigger, the relay is off.
Features:
- Equipped with high-current relay 10A@250VAC / 10A@30VDC
- Can control both AC and DC appliances such as solenoids, motors, lights, fans, etc.
- High-quality screw terminals (Terminal Block) provided (C, NC, NO) for quick and easy connection
- Freewheeling diode to protect your microcontroller
- Input Signal Pin connected to Burg stick for easy accessibility
- LED Status indicators to indicate the relay ON/OFF status
- Mounting holes provided
- Signal input with a high-level signal, the common and often start conduction
- The relay can directly control all kinds of equipment and load
- One often opened a normally closed contact
- Blue KF301 terminal line more convenient
Specifications:
| Trigger Current (mA) | 20 |
|---|---|
| Switching Voltage (VAC) | 250@10A |
| Switching Voltage (VDC) | 30@10A |
| Mounting hole dimensions | Diameter=3mm, X-axis pitch=68mm Y-axis pitch=48mm |
| Length (mm): | 72 |
| Width (mm): | 55.5 |
| Height (mm): | 20 |
Package includes:
1 x 4 Road/Channel Relay Module (with light coupling) 12V
ESP32 LVGL Display: Build a Rich UI on Cheap TFT Screen
Forget bland serial monitor outputs and simple seven-segment displays. With ESP32 LVGL display UI development, you can build...
Read More →
MQTT vs HTTP vs CoAP: IoT Protocol Comparison
Table of Contents Understanding IoT Protocols MQTT: The IoT Standard HTTP and REST APIs for IoT CoAP: Lightweight...
Read More →
Home Automation with ESP32 and Alexa: Full Setup Guide for Indian Homes
Table of ContentsIntroductionHow ESP32 + Alexa WorksHardware & Software RequirementsWiring DiagramMethod 1: Using SinricPro (Easiest)Method 2: Using FauxmoESP...
Read More →Technical Specifications
| Operating Voltage | 12V |
|---|---|
| SKU | AI0323 |
| Weight | 0.05 kg |
| Availability | In Stock |
Applications & Use Cases
The 4 Road/Channel Relay Module 12V (with light coupling) is a versatile relay modules used across a wide range of applications including home automation, industrial control, IoT projects, Arduino/Raspberry Pi interfacing, and motor control.
Common use cases:
- Switching high-voltage AC appliances with a microcontroller
- Building a smart home relay board
- Automating irrigation pumps in agriculture
This product is ideal for electronics engineers, IoT developers, and automation hobbyists.
Technical Tip: Use optocoupler-isolated relay modules to protect your microcontroller. Match relay coil voltage to your MCU logic level (3.3V or 5V).
Shipping & Delivery
- Free shipping on orders above ₹999 across India
- Dispatched within 1-3 business days
- Expected delivery: 3-7 business days depending on location
- Secure packaging to ensure safe transit of electronic components
