16 Pin DIP IC Socket Base Adaptor
16 Pin IC Socket base adaptor is a 16 pin IC holder, which can be soldered directly onto the PCB. The IC can be removed from this socket when required. The IC is placed on the socket at the time of use. This base acts as a removable IC holder.
The socket is used when the IC is temperature sensitive and the heat from the soldering iron can damage the IC. This socket is used when working with a microcontroller IC and can be removed for programming.
Features
- 16 pins.
- JDEC compliant.
- Molded notch for proper orientation.
- Easy to insert and remove ICs.
Specifications:
| Current Handling Capacity (A) | 1 |
|---|---|
| No. of Contact Points | 16 |
| Contact Material | Phosphor Bronze |
| Contact Plating | Tin |
| Operating Temperature (°C) | -25 to 85 |
| Flammability Rating | UL94V-0 |
| Color: | Black |
| Insertion Force | 340g max per contact |
| Exertion Force | 80g max per contact |
| Length (mm): | 20 |
Package Includes
- 1 x 16 Pin DIP IC Socket Base Adaptor(5 pcs).
16 Pin DIP IC Socket Base Adaptor Overview
The 16 Pin DIP IC Socket Base Adaptor (Pack of 5) is a PCB-mountable holder designed to accept 16-pin DIP integrated circuits. It provides a removable, JDEC-compliant interface so you can safely insert or remove ICs for programming, testing, or replacement without risking damage from soldering heat.
Key Features of 16 Pin DIP IC Socket Base Adaptor
- 16-pin configuration supports standard DIP16 packages
- JDEC-compliant footprint ensures compatibility with common PCB layouts
- Molded orientation notch prevents incorrect IC insertion
- Phosphor bronze contacts with tin plating for reliable conductivity
- Package of 5 sockets for bulk projects or spares
- Ships fast from Zbotic warehouse with genuine parts guarantee
Applications and Use Cases
- Prototyping microcontroller circuits where frequent IC swapping is required
- Protecting temperature-sensitive ICs during PCB soldering operations
- Test fixtures for bench-level debugging of digital logic chips
- Educational electronics labs where students practice IC insertion/removal
- Repair and maintenance of legacy DIP-based hardware
How to Use 16 Pin DIP IC Socket Base Adaptor
Solder the socket onto the PCB following the molded notch for correct orientation. Once soldered, align your 16-pin IC with the socket’s notch and gently press it into place. When programming or replacing the IC, simply pull it straight out of the socket without applying heat to the board.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Is the 16 Pin DIP IC Socket Base Adaptor JDEC compliant?
Yes, it follows JDEC standards and fits any PCB designed for a 16-pin DIP socket with 0.1″ pitch.
How many IC swaps can the socket handle?
With durable phosphor bronze contacts and tin plating, you can insert and remove ICs dozens of times with consistent performance.
Why choose a socket instead of soldering IC directly?
The socket protects sensitive ICs from soldering heat, makes programming easier, and lets you swap or upgrade chips without de-soldering.
Technical Specifications
| Pin Count | 16-pin |
|---|---|
| Package Quantity | 5 pcs |
| SKU | AI0620 |
| Weight | 0.005 kg |
| Availability | Out of Stock |
Applications & Use Cases
The 16 Pin DIP IC Socket Base Adaptor (Pack of 5) is a versatile ic base used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
