This is the CW rotation variant of the Original EMAX ECO Micro 1106 2S 6000KV CW Brushless Motor For FPV Racing RC Drone in Drone Motor. Available at ₹1,585.92 (₹1,344.00 + GST) with free shipping across India.
Looking for 2s Brushless Motor? Original EMAX ECO Micro 1106 2S 6000KV CW Brushless Motor For FPV Racing RC Drone is available at Zbotic with fast shipping across India.
2s Brushless Motor – Original EMAX ECO Micro 1106 2S 6000KV CW Brushless Motor
Description:
The new EMAX ECO Micro 1106 brushless motor line sets a new standard in performance for the 2” propeller class. With 2 KV choices each optimized for 2s and 3s batteries for insane speed in a tiny package.
The EMAX ECO Micro 1106 brushless motor has an 8mm tall stator to provide the instantaneous torque that is usually lacking in high KV motors. For micro builds it’s important to have as little mechanical vibration to get the best performance from your flight controller. To ensure smoothness each motor is precision CNC, uses premium ball bearings, and comes factory balanced.
Features:
- Precision durable ball-bearings
- Steel shaft for high strength
- Anodizing for finish and corrosion resistance
- 9×9 mm hole pattern
- Multi-Strand copper windings
- 100mm 26AWG silicone wire
Specification:
| Motor KV (RPM/V) | 6000 |
|---|---|
| Motor Type | Brushless Motor |
| Compatible LiPO Batteries | 2S |
| Framework | 9N12P |
| Prop Shaft (mm) | 1.5 |
| Compatible Prop (inch) | 2 ~ 3 |
| Length (mm) | 19.9 |
| Diameter (mm) | 14.2 |
| Weight (g) | 6.7gm |
Package Includes:
- 1 x EMAX ECO Micro 1106 2S 6000KV CW Brushless Motor For FPV Racing RC Drone
- 1 x Fitting Accessories
Original EMAX ECO Micro 1106 2S 6000KV CW Brushless Motor Overview
The Original EMAX ECO Micro 1106 2S 6000KV CW Brushless Motor is designed for 2″–3″ propeller micro FPV racing and freestyle drones. With a high 6000KV rating and a compact 9N12P framework, it delivers instant torque and precise control for fast, agile flight in tight indoor and outdoor environments.
Key Features of Original EMAX ECO Micro 1106 2S 6000KV CW Brushless Motor
- 9N12P stator design with 8 mm height for strong, responsive torque
- 6000KV optimized for 2S LiPo setups, delivering up to 214 g of thrust
- Precision CNC machined components for minimal vibration and smooth performance
- CW-only rotation with 1.5 mm prop adapter shaft fitting standard micro props
- Lightweight and compact for 2″–3″ propeller mounts on micro racing builds
- Genuine EMAX motor with fast shipping across India from Zbotic
Applications and Use Cases
- Micro FPV racing drones using 2″ or 2.5″ props on 2S LiPo batteries
- Tiny freestyle quads where lightweight, high-RPM motors boost agility
- Indoor cinewhoop frames requiring low-vibration, high-thrust drive units
- Spare or upgrade motors for existing micro drone repairs and tuning
- DIY micro drone prototypes testing different prop sizes and thrust levels
How to Use Original EMAX ECO Micro 1106 2S 6000KV CW Brushless Motor
Mount the motor on a compatible micro drone arm using M1.5 screws and secure it with thread locker for vibration resistance. Slide on a 2″–3″ propeller onto the 1.5 mm shaft adapter and tighten the prop nut. Connect motor leads to a compatible 2S-capable ESC, calibrate throttle endpoints, and ensure balanced props for smooth flight. Power with a 2S LiPo and adjust PID gains to suit your drone’s frame and weight.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What propeller sizes are compatible with this motor?
This EMAX ECO Micro 1106 motor supports 2″ to 3″ propellers, optimized for 2S LiPo setups to deliver smooth thrust and high RPMs.
Can I use a 3S LiPo battery with this motor?
No. The motor is specifically designed and wound for 2S LiPo only. Running a 3S pack may overheat the windings and void the warranty.
What shaft adapter does the motor use?
The motor features a 1.5 mm diameter propeller adapter shaft to fit standard micro drone prop hubs securely.
