PRODUCT DESCRIPTION
The ME-8107 Rotary Adjustable Roller Mini Limit Switch, commonly referred to as the POSITION SWITCH, is a frequently used small current main electrical device. Its contact mechanism activates through the interaction with moving parts in production machinery or a segmented control circuit to achieve a designated control purpose.
Widely employed as an electrical control switch in mechanical and various other industries, this Limit Switch is integral in a multitude of machines for tracking the position of their moving components. It is imperative to check the Voltage Rating to confirm compatibility with your local voltage to ensure the Limit Switch functions properly.
Features:
- Actuator action: momentary.
- Actuator-type rotary adjustable lever arm with a roller.
- Contact configuration 1 NC 1 NO.
- Actuator Type Adjustable Rod Arm
Specifications:
- Model: ME-8107
- Action Type: Momentary
- Contact Type: DPST
- Contact Configuration: 1 NC 1 NO
- Mounting Hole Spacing: 56 x 21mm
- Rating: AC 250V/5A DC 115V/0.4A
- Rod Length: 140mm
- Cable Entry Diameter: 6mm
- Mounting Thread Diameter: 4.5mm
- Main Color: Blue, Black
- Material: Plastic, Metal, Rubber
- Main Body Size: 64 x 28 x 25mm
- Net Weight: 85g
Package Includes:
1 x ME-8107 Rotary Adjustable Roller Mini Limit Switch
ME-8107 Rotary Adjustable Roller Mini Limit Switch Overview
The ME-8107 Rotary Adjustable Roller Mini Limit Switch is a compact DPST position switch featuring a momentary rotary actuator with a roller lever for precise mechanical detection. It’s designed to monitor end-of-travel positions in machinery and control circuits, ensuring reliable on/off signals in automated systems.
Key Features of ME-8107 Rotary Adjustable Roller Mini Limit Switch
- DPST Contact Configuration: Provides two poles with 1 NC and 1 NO contact for versatile switching options.
- Momentary Actuator Action: Rotary adjustable lever arm with roller for accurate and repeatable activation.
- Wide Voltage Rating: Supports AC 250V/5A and DC 115V/0.4A for diverse industrial applications.
- Compact Footprint: Mounting hole spacing of 56 × 21 mm fits into tight machine frames.
- Durable Construction: Robust metal roller and lever mechanism withstand frequent cycling.
- Fast Shipping from Zbotic: Genuine ME-8107 units dispatched within 24 hours.
Applications and Use Cases
- Position detection on CNC machine axes to prevent overtravel.
- End-of-line sensing on conveyor belts for sorting and stopping.
- Door or guard monitoring in packaging equipment.
- Limit detection on robotic arms to define safe motion range.
- Machine tool ram position feedback in presses and stamping units.
How to Use ME-8107 Rotary Adjustable Roller Mini Limit Switch
Mount the switch using two M4 screws aligned to the 56 × 21 mm holes, wire the common terminal to your power source and connect the load to the NC or NO terminal as needed. Adjust the roller lever angle by loosening its pivot screw, positioning the roller against the moving part, then retightening. Verify operation under AC 250V/5A or DC 115V/0.4A conditions.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
How do I wire the ME-8107 switch for normally closed operation?
Connect your supply to the common terminal (COM) and route the load to the NC terminal. When the roller lever isn’t actuated, the NC contacts remain closed and open upon actuation.
Can I adjust the actuation point of the roller lever?
Yes. Loosen the lever’s mounting screw, rotate the adjustable roller arm to your desired angle or position, then retighten the screw to lock the lever in place.
What mounting hardware is required?
The switch uses two M4 screws spaced 56 × 21 mm apart. Use standard M4 nuts or screw assemblies to secure the switch onto your machine frame.
