MAD CO 4012 EEE brushless motor 480KV (Pack Of 2)
Description:
The MAD CO 4012 EEE Brushless Motor 480KV (Pack of 2) is a high-performance motor designed for UAVs, drones, and other demanding aerial applications. Built with a durable Taiwan stator and anti-corrosive varnished wire rated at 150°C, this motor ensures long-lasting stability and reliability. Its advanced centrifugal heat dissipation system, rainproof protection, and precision-balanced rotor deliver smooth and efficient operation. With a maximum thrust of 3.4 kg, torque up to 0.6 Nm, and a power output of 718W, it is ideal for quadcopters, hexacopters, and octocopters. Perfectly matched with MAD AMPX PRO 40A ESC, it supports a wide range of propellers for versatile flight performance.
Note: Refer to datasheet in the ATTACHMENTS section for more info. regd. the product.
Features:
- High-quality 4012 EEE brushless motor with 480KV rating
- Taiwan stator with anti-corrosive varnished wire (150°C rated)
- Rainproof design with centrifugal heat dissipation
- Lightweight yet powerful with max thrust of 3.4 kg
- Precision-balanced rotor (≤5 mg) for smooth operation
- Includes prop adapters, bullet connectors, and mounting hardware
Application:
- Aerial cinematography drones
- Heavy-lift quad/hex/octocopters
- Payload delivery UAVs
- Industrial inspection drones
- Agricultural spraying/mapping drones
- Custom UAV and VTOL projects
Specification:
| Item Type: | Drone motor |
|---|---|
| Model No: | 4012 |
| Motor KV (RPM/V): | 480 |
| Motor Type: | EEE brushless drone motor |
| Compatible LiPO Batteries: | 6S LiPo |
| No-load current (A) | 1.4 @ 20V |
| Max Current (A) | 30.5 |
| Max Power Output (W) | 718 |
| Torque: | 0.6 Nm |
| Max Thrust | 3.4 kg |
| Shaft Diameter (mm): | 05 |
| Bearing | EZO 685ZZ*1 / EZO 695ZZ*1 |
| Mounting Hole(mm) | D:12 M3×4 |
| Motor Size (mm): | D:44.5 × 26.1 |
| Motor Outer Diameter(mm) | 44.5 |
Package Includes:
1 x MAD CO 4012 EEE brushless motor 480KV (Pack Of 2)
2 x Propeller Plate
6 x 3.5mm Bullet Connector
2 x 04-6 Adapter Ring
6 x Heat Shrinkable Tube
8 x M3*6 Motor Screws
4 x M3*10 Propeller Screws
2 x Sticker
