Looking for Mn501 Motor T -motor? T Motor MN501-S KV360 is available at Zbotic with fast shipping across India.
Features:
- Strong power ,long service life
- Excellent cooling performance
- Anti-high temperature/Anti-overload
- Dust-resistance/Waterproof/Anti-corrosion
Specifications:
- Motor size: 55.6°33.9mm
- Stator Imported silicon steel sheet; Anti-rust treatment; 150°Chigh temperature-resisting coatings
- Configuration 24N28P
- Shaft Diameter IN: 6mm, OUT: 4mm
- Bearing: Imported 696ZZ
- Magnet Level: 180°C high temperature resistance
- Silicon Cable: 16AWG x 150MM
- Copper Wire: 220°C high temperature resistance: Level C
- Coil Insulation Test: 500V
- Centrifugal Cooling Design: YES
- Rotor Dynamic Balance Standard: <5Mg
- Motor Dynamic Balance Standard: <10Mg
- IP: IP45
- KV: 360
- Idle Current ( 15V): 1.4A
- Peak Current (180s ): 40A
- Max. Power (180s ): 1000w
- Internal Resistance: 45mQ.
- Rated Voltage (Lipo): 6s
- ESC Recommendation: AIR 40A
- Propeller Recommendation: 17-18″
- Motor Weight (Incl. Cable): 175g
- Package Weight: 350g
Packages Includes:
1 x T Motor MN501-S KV360
T Motor MN501-S KV360 Overview
The T Motor MN501-S KV360 is a high-performance brushless DC motor designed for heavy-lift and long-endurance drone applications. With a KV rating of 360 and compatibility with 6S LiPo batteries, it delivers up to 1000W of peak power and precise thrust control for professional multicopters.
Key Features of T Motor MN501-S KV360
- High Power Output: Delivers 1000W peak power at 40A for stable lift under heavy payloads.
- Efficient Cooling: Centrifugal cooling design plus 180°C heat-resistant magnets ensure thermal stability.
- Durable Construction: Imported silicon steel stator with anti-rust treatment and 220°C high-temperature copper windings.
- All-Weather Reliability: Dust-resistant, waterproof and anti-corrosion coatings for harsh environments.
- Precision Balance: Rotor dynamic balance under 5 mg minimizes vibration for smooth flight.
- Fast Shipping & Genuine: Zbotic ships authentic T Motor products within 24 hours across India.
Applications and Use Cases
- Heavy-lift photography and videography drones carrying large cameras.
- Long-range FPV racing quadcopters requiring consistent high thrust.
- Industrial inspection UAVs transporting sensors and LiDAR modules.
- Agricultural spray drones needing stable flight under load.
- Research and development platforms testing novel airframe designs.
- Cargo delivery drones for small package transport.
How to Use T Motor MN501-S KV360
Secure the MN501-S KV360 to your drone’s motor mounts using the 6 mm shaft adapter and M5 screws. Solder or bullet-connect the three phase wires to a 6S-compatible ESC rated above 40 A, then balance the chosen propeller on the 4 mm shaft end. Power up with a fully charged 6S LiPo battery, calibrate throttle endpoints on your flight controller, and perform a hover test to verify smooth operation and temperature.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What ESC should I pair with the MN501-S KV360?
We recommend a brushless ESC that supports 6S LiPo and provides at least 40 A continuous current. This ensures optimal throttle response and prevents overheating during high-load flights.
Can I use this motor with larger propellers?
Yes, the KV360 motor is optimized for 6–7 inch propellers. Using quality 6–7 inch props will maximize thrust efficiency while keeping current draw within safe limits.
How do I maintain the MN501-S KV360 for longevity?
Inspect bearings periodically for smooth rotation, clean off dust or debris from cooling vents, and ensure all solder joints and connectors remain corrosion-free. Store in a dry environment to protect anti-corrosion coatings.
DIY Electric Wheelchair Motor Controller: L298N High Amp Guide
Building or modifying an electric wheelchair motor controller is one of the most meaningful DIY electronics projects you...
Read More →
RC Servo Tester: How to Test Servos Without a Microcontroller
You have a bag of servo motors from your last robotics project, a spare SG90 from a crashed...
Read More →
FPV Simulator Training: Velocidrone and Liftoff Guide
Table of Contents Understanding FPV Simulator Training Key Components and Requirements Step-by-Step Setup Guide Configuration and Optimisation Practical...
Read More →Technical Specifications
| Brand | T -Motor |
|---|---|
| Model | MN501-S |
| SKU | AI1653 |
| Weight | 0.455 kg |
| Availability | In Stock |
Applications & Use Cases
The T Motor MN501-S KV360 is a versatile drone motor used across a wide range of applications including FPV racing drones, agricultural spray drones, aerial photography platforms, and custom multirotor builds.
Common use cases:
- Replacement motor for crashed or worn-out drone
- Building a custom quadcopter or hexacopter from scratch
- Upgrading to a more efficient motor for longer flight times
This product is ideal for drone builders, FPV pilots, and agricultural drone operators.
Technical Tip: When selecting a drone motor, match the KV rating to your propeller size and battery voltage. Lower KV = larger props + more efficiency; higher KV = smaller props + more speed.
