This is the Red variant of the Correlation Photoelectric Infrared Count Slot Sensor Module 10 mm in Rotary Encoder. Available at ₹56.40 (₹47.80 + GST) with free shipping across India.
Looking for 10mm Module? Correlation Photoelectric Infrared Count Slot Sensor Module 10 mm is available at Zbotic with fast shipping across India.
10mm Module – Correlation Photoelectric Infrared Count Slot Sensor Module 10 mm
- Introducing the Correlation Photoelectric Infrared Count Slot Sensor Module, featuring a 10mm optical coupling slot that provides high-quality infrared counting at an affordable price.
- This module includes an integrated LM393 chip and boasts a compact design, making it suitable for various applications. Whether you’re testing motor speed, counting items in industrial settings, or tracking workpieces, this sensor module offers reliable performance with ease.
- – Optical coupling slot width: 10mm
– Single signal output with indication
– Convenient circuit board output switch
– Low valid signal output
– Compatible with multiple microcontrollers for seamless integration
– Ideal for workpiece counts and industrial applications - With its precise object detection capabilities and user-friendly operation, the Correlation Photoelectric Infrared Count Slot Sensor Module is the perfect solution for your project needs.
Note: The sensitivity is not adjustable.
Features
- The width of the optical coupling slot: 10mm
- With a signal output indication.
- Single signal output
- The circuit board output switch!
- The output valid signal is low.
- It is useful for workpiece counts.
- It’s also useful for industry counting, motor speed testing .
Specifications:
| Main Chip | LM393 |
|---|---|
| Operating Voltage (VDC) | 3.6 ~ 5 |
| Average Current Consumption (mA) | 33 |
| Length (mm): | 27.6 |
| Width (mm): | 20 |
| Height (mm): | 17 |
| Weight (g): | 4 |
| The width of the optical coupling slot | 10 mm |
Package Includes:
- 1 x Correlation photoelectric Infrared count Slot sensor module.
Correlation Photoelectric Infrared Count Slot Sensor Module Overview
The Correlation Photoelectric Infrared Count Slot Sensor Module is a compact optical interrupter featuring a 10 mm-wide coupling slot and an onboard LM393 comparator. It provides a single digital output that goes low when an object interrupts the infrared beam, making it ideal for counting parts or measuring motor speed in industrial and DIY applications.
Key Features of Correlation Photoelectric Infrared Count Slot Sensor Module
- 10 mm optical coupling slot for reliable beam interruption detection
- Single digital output with active-low valid signal
- Integrated LM393 comparator for stable threshold switching
- Compact PCB design for easy mounting and wiring
- Suitable for counting, speed measurement, and position sensing
- Genuine product with fast shipping from Zbotic
Applications and Use Cases
- Counting workpieces on an assembly line
- Measuring rotational speed of motors or shafts
- Monitoring product flow on conveyor belts
- Detecting object passage in packaging machines
- DIY robotics for wheel encoder feedback
- Educational labs demonstrating photoelectric sensing
How to Use Correlation Photoelectric Infrared Count Slot Sensor Module
Connect the module’s VCC (3.3–5 V) and GND to your controller, then wire the output pin to a digital input with a pull-up resistor. Position the sensor so the target object passes through the 10 mm slot, interrupting the IR beam. Each beam break pulls the output low, allowing you to count pulses or calculate speed via your microcontroller’s interrupt or polling routine.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What type of output signal does this slot sensor provide?
The module delivers a single digital output that remains high under no obstruction and goes low when an object blocks the infrared beam within the 10 mm slot.
Which objects can be detected with this infrared count slot module?
Any opaque object—such as metal parts, plastic widgets, or cardboard—that fits into the 10 mm slot will interrupt the beam and trigger the sensor’s output.
How do I interface this sensor with a microcontroller?
Simply wire the output to a digital input pin, enable an internal or external pull-up resistor, and write firmware to count falling edges. Use interrupts or polling to record each beam interruption for speed or quantity measurements.
Technical Specifications
| Size | 10mm |
|---|---|
| Color | Red |
| SKU | AI1047 |
| Weight | 0.0 kg |
| Availability | Out of Stock |
Applications & Use Cases
The Correlation Photoelectric Infrared Count Slot Sensor Module 10 mm is a versatile rotary encoder used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
Shipping & Delivery
- Free shipping on orders above ₹999 across India
- Dispatched within 1-3 business days
- Expected delivery: 3-7 business days depending on location
- Secure packaging to ensure safe transit of electronic components
