PRODUCT DESCRIPTION
The CC1101 is a low-power transceiver designed for wireless communication in the ISM (Industrial, Scientific, and Medical) and SRD (Short Range Device) frequency bands, primarily operating at 868 MHz, but capable of functioning between 779 MHz and 928 MHz.
This device features a configurable baseband modem that supports various modulation formats and data rates up to 600 kbps. It also includes hardware features for packet handling, data buffering, burst transmissions, clear channel assessment, link quality indication, and wake-on-radio functionality. The CC1101’s key settings, along with its 64-byte transmit/receive FIFOs, are accessible via an SPI interface, enabling easy integration with a microcontroller.
A typical system using the CC1101 transceiver consists of a microcontroller, a few passive components, and the CC1101 module itself, making it a versatile solution for a wide range of wireless applications.
Connection Diagram:
Features:
- Support FSK, GFSK, ASK / OOK and MSK
- Configurable data rate: 1.2k to 500kps
- Vertical Pin header (1.27mm pitch)
- Low voltage input (1.9~3.6V)
- SPI interface
- Independent 64-byte RX and TX data FIFOsCC1101 Core, 433MHz Wireless function
Note : Actual product may be different in terms of metal spring
Package Includes:
1 x CC1101 868MHZ Wireless Transceiver Module with Antenna，round Hole
CC1101 868MHZ Wireless Transceiver Module with Antenna Overview
The CC1101 868MHZ Wireless Transceiver Module with Antenna is a low-power RF device designed for reliable wireless communication in the 868 MHz ISM/SRD band. Ideal for embedded projects, it delivers configurable data rates and multiple modulation options to suit remote control, telemetry, and sensor networks.
Key Features of CC1101 868MHZ Wireless Transceiver Module with Antenna
- Supports FSK, GFSK, ASK/OOK and MSK modulation formats
- Configurable data rate from 1.2 kbps up to 500 kbps
- Vertical 1.27 mm pitch pin header for easy PCB integration
- Low-voltage operation from 1.9 V to 3.6 V for battery-powered designs
- SPI interface for register configuration and data transfer
- Independent 64-byte RX and TX FIFOs for efficient packet handling
- Includes pre-tuned 868 MHz antenna with round-hole connector
- Fast shipping across India from Zbotic
Applications and Use Cases
- Remote sensor networks in agriculture and environmental monitoring
- Home and industrial automation control links
- Wireless alarm and security system communication
- Smart metering and utility data collection
- Low-power telemetry for robotics and UAV telemetry
- Point-to-point data links in IoT prototypes
How to Use CC1101 868MHZ Wireless Transceiver Module with Antenna
Begin by soldering the vertical pin header to your PCB or breadboard, then connect VCC (1.9 V–3.6 V), GND, and SPI lines (MOSI, MISO, SCK, CS) to your microcontroller. Attach the supplied 868 MHz antenna to the round-hole connector. Configure the CC1101 registers over SPI for desired modulation and data rate, then use the TX FIFO to send data or monitor the RX FIFO for incoming packets.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Q: What voltage supply does this module require?
The CC1101 module operates from 1.9 V up to 3.6 V, making it suitable for direct connection to common battery sources or 3.3 V MCU rails.
Q: Which interface is used to communicate with the CC1101?
This transceiver uses an SPI interface for all configuration and data exchange, allowing easy integration with most microcontrollers.
Q: Is the antenna included and pre-tuned?
Yes, the module ships with a pre-tuned 868 MHz antenna attached via a round-hole connector, ready for immediate use in the ISM band.
Technical Specifications
| Model | CC1101 |
|---|---|
| Frequency | 868MHZ |
| SKU | AI2993 |
| Weight | 0.0026 kg |
| Availability | Out of Stock |
Applications & Use Cases
The CC1101 868MHZ Wireless Transceiver Module with Antenna ,round Hole is a versatile ir and rf transmitters and receivers used across a wide range of applications including remote control systems, wireless data links, home automation, security systems, and garage door openers.
Common use cases:
- Building a custom remote control
- Adding wireless triggering to a project
- Creating a simple wireless sensor link
This product is ideal for electronics hobbyists and IoT developers.
Technical Tip: 433MHz modules offer longer range; IR is line-of-sight only. RF modules need matched transmitter/receiver pairs.
Shipping & Delivery
- Free shipping on orders above ₹999 across India
- Dispatched within 1-3 business days
- Expected delivery: 3-7 business days depending on location
- Secure packaging to ensure safe transit of electronic components
