Description:
This is a High Precision Signal Amplifier Board/Voltage Amplifier Module based on the AD620 Instrumentation Amplifier IC.
- Input Voltage Range: DC 3~12V
- Amplification: Adjustable 1.5~1000 times
- Adjustable Zero: Improves accuracy
- Can be used for AC and DC signal amplification
Key Features:
- Wide Input Range:
- Uses AD620 to amplify microvolts and millivolts.
- Offers higher amplification precision and better linearity than LM358.
- Maximum voltage output range: ±10V
- Magnification:
- Uses a potentiometer to amplify the input signal.
- Amplification up to 1000 times, adjustable via the potentiometer.
- Adjustable Zero-Point:
- Adjust the zero point using the zeroing potentiometer to improve accuracy.
- Prevents zero drift phenomenon.
- Negative Voltage Output:
- Module uses a 7660A negative voltage chip to output negative voltage (-Vin).
- Can be used to drive other dual power loads
Specifications:
| Operating Voltage (VDC): | 3 ~ 12 |
|---|---|
| Amplification | Adjustable 1.5~1000 times |
| Signal Input Voltage Range | 100µV~300mV |
| Signal Output Range | ± (Vin-2V) |
| Offset Voltage | 50µV |
| Input Bias Current | 1.0nA (Max) |
| Common Mode Rejection Ratio | 100dB |
| Offset Voltage Drift | 0.6µV |
| Length (mm): | 22 |
| Width (mm): | 33 |
| Height (mm): | 14 |
Package Includes:
- 1 x AD620 Microvolt/Millivolt Voltage Amplifier Module
- 2 x 4 Pin Male Header
Technical Specifications
| Model | AD620 |
|---|---|
| SKU | AI0645 |
| Weight | 0.01 kg |
| Availability | Out of Stock |
Applications & Use Cases
The AD620 Microvolt/Millivolt Voltage Amplifier Module is a versatile buck boost voltage regulators used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
- Integrating into a custom electronics project
- Learning and experimenting with circuits
- Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
