5V Single Channel Relay Module
This 5V 1A Relay Module is a versatile electromagnetic switch capable of controlling both AC and DC loads. When the coil inside is energized with a small current, it triggers the relay to switch a high current circuit ON or OFF. The module comes with PCB screw terminals, making it easy to connect directly to your circuits.
Ideal for a range of applications, this relay module is commonly used in home automation systems to control appliances, in electronic circuits for switching tasks, and in safety circuits to disconnect or connect heavy loads during emergencies. It is also widely applied in automotive systems, such as activating windscreen wipers, power windows, fuel pumps, and cooling fans.
Input and output connection:
- 3 input male header pin
- Pin configuration is +,in,-
- Output or switching pins are NO, CM, NC.
- Input voltage is 5V
- Operating current 50mA
- Output capacity is 250v,7A ,120v 12A or 24VDC,10A
- Provided Input signal should be negative.
Package Includes:
- 1 × Single Channel 5V Relay Module – Made in India
5V Single Channel Relay Module Overview
The 5V Single Channel Relay Module (Made In India) is an electromagnetic switching board designed to control high-current AC or DC loads using a 5V control signal. Its single relay channel makes it ideal for integrating with microcontrollers, PLCs or manual switches to switch devices up to 10A safely.
Key Features of 5V Single Channel Relay Module
- Operating Voltage: 5V DC control input
- Coil Current Draw: Up to 20mA for energizing relay
- High Switching Capacity: 10A at AC250V and 10A at DC5V
- Single Channel: One SPDT relay for simple on/off control
- PCB Screw Terminals: Easy wiring for both control signal and load connections
- Made in India & Fast Shipping from Zbotic across India
Applications and Use Cases
- Home automation to switch lights, fans or pumps via microcontroller
- Safety circuits for emergency power cutoff in machinery
- Automotive circuits to control horns, lights or auxiliary devices
- Industrial control panels for turning motors or solenoids on/off
- DIY electronics projects requiring isolation between logic and high voltage
How to Use 5V Single Channel Relay Module
Connect the module’s VCC to a stable 5V supply and GND to your system ground. Drive the IN pin with a digital output (e.g., from Arduino) to energize the relay coil. Wire your high-voltage load between the COM (common) and NO (normally open) or NC (normally closed) screw terminals. When IN goes high, the relay switches, safely isolating the control circuit from the load.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What is the trigger current required for the relay coil?
The relay coil operates at 5V DC and draws up to 20mA when energized. Ensure your control signal can supply this current or use a driver transistor if needed.
Can this module switch both AC and DC loads?
Yes, the relay contacts are rated for up to 10A at AC250V or DC5V, allowing you to control a variety of AC and DC appliances or circuits safely.
Is this relay module compatible with Arduino or Raspberry Pi?
Absolutely. The module’s IN pin accepts a 5V logic signal, making it directly compatible with 5V microcontrollers like Arduino. For 3.3V systems, use a level shifter or driver transistor to ensure reliable activation.
