Looking for 5mpa Stainless Steel Sensor? 5MPa Stainless Steel Pressure Transducer Sensor is available at Zbotic with fast shipping across India.
Product Description
This is a Pressure Transducer from Zbotic.in’s new product line. It is made of high-quality stainless steel for durability. It has a standard G1/4 thread size and can work with both air and water. It operates at 5VDC and gives a digital output between 0.5V and 4.5V. It has stable performance and a long service life.
Applications:
- Pressure Detection in Oil Tank, Gas Tank.
Features:
- Adopt Precision Compensation Technology and Sensitive Components, Stable and Reliable.
- 0.1% FS Small Output Error, Including Nonlinear, Hysteresis Error, and Repeatability.
- Light Weight and Small Volume, Easy to Install, and Operate.
- Stainless Steel Body, it has Complete Surge Voltage Protection Function.
Package Includes:
1 x 5MPa Stainless Steel Pressure Transducer Sensor
Datasheet:
5MPa Stainless Steel Pressure Transducer Sensor Overview
The 5MPa Stainless Steel Pressure Transducer Sensor is a compact, high-accuracy device designed to measure pressures up to 5 MPa in gas, liquid or oil systems. Its robust stainless steel housing, standard G1/4 thread interface, and 5 VDC supply requirement make it ideal for industrial and laboratory applications.
Key Features of 5MPa Stainless Steel Pressure Transducer Sensor
- Stainless steel body ensures corrosion resistance and durability
- Measurement range up to 5 MPa for gas, liquids and oil
- Precision compensation technology with 0.1% FS total error
- Compact design with standard G1/4 thread for easy installation
- Operates on 5 VDC, outputs 0.5–4.5 V signal proportional to pressure
- Lightweight construction with stable performance and long service life
- Genuine product with fast shipping across India from Zbotic
Applications and Use Cases
- Pressure monitoring in oil storage tanks
- Gas cylinder and pipeline pressure measurement
- Water supply line and pump system pressure control
- Hydraulic equipment performance testing
- Industrial process pressure feedback loops
- Laboratory experiments requiring precise pressure data
How to Use 5MPa Stainless Steel Pressure Transducer Sensor
Secure the sensor into the system using the G1/4 threaded port, ensuring a leak-free seal. Connect a stable 5 VDC power supply to its input terminals, and wire the output pin to an analog-to-digital converter or data acquisition unit. Calibrate zero and full-scale points if necessary, then immerse the sensing element in the fluid or attach to the gas line. Monitor the 0.5–4.5 V output, which directly corresponds to the 0–5 MPa pressure range.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What voltage supply does this sensor require?
The sensor operates on a stable 5 VDC supply, delivering a proportional output voltage between 0.5 V and 4.5 V.
What is the output signal range for pressure readings?
The transducer provides a linear voltage output from 0.5 V at 0 MPa to 4.5 V at 5 MPa, suitable for direct interface with analog input modules.
Is the sensor compatible with both gas and liquid media?
Yes, the stainless steel construction and precision components allow reliable measurement in gas, liquid and oil applications up to 5 MPa.
