0.56 inch Red 2 Digit 7 Segment LED Display CC – 18Pin
Introducing the 0.56-inch Red 2 Digit 7 Segment LED Display CC – 18Pin, a versatile component perfect for a variety of applications. This LED display provides outstanding clarity and reliability, making it an excellent choice for numerous electronic projects. Here are the key features:
Features:
Bright Red LED chip ensures excellent visibility in any lighting conditions.
Blackface design with Red LED segments for enhanced contrast and readability.
Type: Common cathode, offering flexibility in circuit design.
Equipped with 18 pins for seamless integration into your projects.
Low current consumption for energy-efficient operation.
High brightness for clear and vibrant display of numerical data.
Easy to use with PCB mounting or on breadboard setups.
This LED display is perfect for displaying numerical data accurately and effectively in your DIY electronics projects. Whether you’re building a digital clock, a timer, or any other device that requires numeric display, this 7 segment LED display is the perfect choice.
Specifications:
Display Type
Seven segments
Configuration
Common Cathode
No. of Pins
12
LED colour
RED
No. of Digits
2 Digits
Digit Height
14mm
Operating current
10mA
Wavelength
640nm
Length (mm):
25.20
Width (mm):
19
Height (mm):
8
Weight (g):
3 (each)
Package Includes
1 x 0.56 Inch Red 2-Digit 7 Segment LED Display CC
0.56 inch Red 2 Digit 7 Segment LED Display CC – 18Pin Overview
The 0.56 inch Red 2 Digit 7 Segment LED Display CC – 18Pin is a dual‐digit numeric display module with a common cathode configuration. Featuring bright AlGaAs red LED segments on a blackface substrate, it’s ideal for clear numeric readouts in DIY electronics, counters, clocks and instrumentation panels.
Key Features of 0.56 inch Red 2 Digit 7 Segment LED Display CC – 18Pin
0.56″ Red LED chip for high‐visibility numeric display
Common cathode design with two separate digits for flexible multiplexing
18‐pin DIP package for straightforward PCB integration
Blackface background enhances contrast and readability
Low current consumption (typical 10-20 mA per segment) for energy‐efficient use
Fast shipping from Zbotic: orders dispatched within 24 hours
Applications and Use Cases
Digital clocks and timers in hobbyist electronics
Counter displays for event tallies or frequency counters
Voltage or current readouts in bench power supplies
Temperature and humidity monitors with numeric output
How to Use 0.56 inch Red 2 Digit 7 Segment LED Display CC – 18Pin
Connect each segment pin through a 220 Ω resistor to your microcontroller’s digital outputs and tie both common cathode pins to ground. Use multiplexing to drive each digit in rapid succession, ensuring only one digit’s cathode is grounded at a time for stable two-digit display. Mount the 18-pin DIP package onto your PCB or breadboard for easy prototyping.
Why Buy from Zbotic?
Genuine Products: All items sourced from authorized distributors
Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
Free Shipping: Free delivery on qualifying orders
COD Available: Cash on Delivery, UPI, cards, net banking
Technical Support: Expert help for setup and troubleshooting
Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
Can I drive this display directly from an Arduino?
Yes. Each segment draws about 10–20 mA at 5 V. Use one 220 Ω resistor per segment pin and connect the two common cathode pins to Arduino GND. For sustained display of both digits, implement multiplexing in your sketch.
What resistor value should I use with this display?
A 220 Ω resistor per segment is recommended at a 5 V supply to limit current to approximately 15 mA, balancing brightness and LED lifespan. Adjust up to 330 Ω for lower current and reduced power draw.
How do I wire the common cathode pins?
This module has two common cathode pins—one for each digit. Tie both cathode pins to ground and switch them on/off individually during multiplexing to select which digit is active.
The 0.56 inch Red 2 Digit 7 Segment LED Display CC - 18Pin is a versatile seven segment display used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
Integrating into a custom electronics project
Learning and experimenting with circuits
Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
Shipping & Delivery
Free shipping on orders above ₹999 across India
Dispatched within 1-3 business days
Expected delivery: 3-7 business days depending on location
Secure packaging to ensure safe transit of electronic components
Weight
0.004833 kg
Dimensions
3 × 3 × 2 cm
15 Days Warranty
Please note that this item is only covered by a standard supplier warranty against manufacturing defects for a period of 15days from the time of delivery. It is important to understand that only manufacturing defects are covered under this warranty, and any other issues will not be considered for reimbursement or replacement. We strongly advise inspecting the product upon delivery to ensure it meets your expectations. In case of any manufacturing defects, we guarantee reimbursement or replacement.
What voids warranty:
If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.
