YXC – HC-49SMD 14.7456MHZ 20PF 20PPM 2Pad SMD/SMT Quartz Crystal (Pack of 2)

Looking for Yxc – Hc 14.7456mhz? YXC – HC-49SMD 14.7456MHZ 20PF 20PPM 2Pad SMD/SMT Quartz Crystal (Pack of 2) is available at Zbotic with fast shipping across India.

YXC – HC-49SMD 14.7456MHZ 20PF 20PPM 2Pad SMD/SMT Quartz Crystal (Pack of 2)

Introducing the YXC HC-49SMD Quartz Crystal, a reliable and precise component essential for various electronic applications. This pack includes 2 crystals, ensuring you have a backup for your projects or replacements when needed.

With a frequency of 14.7456MHz, these crystals offer stable performance suitable for demanding circuitry. Their 20pF load capacitance and 20PPM frequency tolerance ensure accurate timing in your designs, making them ideal for applications where timing is critical.

Designed for surface mount technology (SMT), these crystals are easy to install and integrate into your PCB designs. The HC-49SMD package ensures secure mounting and compatibility with modern manufacturing processes.

Whether you’re working on telecommunications, microcontrollers, or other electronic projects, the YXC HC-49SMD Quartz Crystals provide the precision and reliability you need. Upgrade your designs with these high-quality components and experience improved performance and stability.

Features:

1. Frequency: 14.7456MHz – Offers a stable frequency suitable for various electronic applications including microcontrollers, communication systems, and timing circuits.
2. Load Capacitance: 20pF – Provides the necessary load capacitance for optimal performance in your circuit designs.
3. Frequency Tolerance: ±20PPM – Ensures accurate timing and synchronization in your electronic devices, even under varying environmental conditions.
4. Package Type: SMD/SMT (Surface Mount Device/Surface Mount Technology) – Enables easy integration onto printed circuit boards (PCBs), simplifying the manufacturing process and reducing assembly time.
5. Packaging: Pack of 2 – Provides convenience and flexibility for your projects, with a spare crystal included for backup or replacement purposes.
6. Reliability: YXC brand – Known for producing high-quality electronic components, ensuring reliability and longevity in your applications.
7. Compact Design: HC-49SMD package – Offers a compact footprint, suitable for space-constrained designs without compromising performance.

Package Includes

• 1 x YXC – HC-49SMD 14.7456MHZ 20PF 20PPM 2Pad SMD/SMT Quartz Crystal (Pack of 2)

YXC – HC-49SMD 14.7456MHZ 20PF 20PPM 2Pad SMD/SMT Quartz Overview

The YXC HC-49SMD 14.7456MHz quartz crystal is a surface-mount resonator designed for precision timing in electronic circuits. With a tight ±20PPM frequency tolerance and 20pF load capacitance, it delivers stable oscillation for communication modules, microcontrollers, and RF devices. Packaged in an HC-49SMD format with two pads, it simplifies PCB assembly and maintenance.

Key Features of YXC – HC-49SMD 14.7456MHZ 20PF 20PPM 2Pad SMD/SMT Quartz

• Precise 14.7456MHz oscillation frequency with ±20PPM tolerance
• 20pF load capacitance optimized for stable startup and low drift
• Compact HC-49SMD package with 2-pad SMT footprint for automated placement
• Pack of 2 crystals—ideal for prototyping and having a spare on hand
• Genuine YXC components sourced from authorized distributors
• Fast shipping across India from Zbotic, with orders dispatched within 24 hours

Applications and Use Cases

• External clock source for microcontrollers and development boards
• Baud rate generation in UART, RS-232, or TTL serial interfaces
• Reference oscillator in RF transceivers and wireless communication modules
• Frequency standard in PLL circuits and frequency synthesizers
• Timing element in digital signal processing (DSP) applications
• Timebase for real-time clocks and timer peripherals

How to Use YXC – HC-49SMD 14.7456MHZ 20PF 20PPM 2Pad SMD/SMT Quartz

Place the crystal on a PCB footprint matching the HC-49SMD 2-pad layout, then solder using a controlled reflow profile. Add two 20pF load capacitors (one per pad to ground) as close as possible to the crystal pins to ensure correct oscillation. Follow your microcontroller or oscillator IC datasheet for recommended grounding and trace routing to minimize noise.

Why Buy from Zbotic?

• Genuine Products: All items sourced from authorized distributors
• Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
• Free Shipping: Free delivery on qualifying orders
• COD Available: Cash on Delivery, UPI, cards, net banking
• Technical Support: Expert help for setup and troubleshooting
• Easy Returns: Hassle-free replacement for defective products

Frequently Asked Questions

What is the load capacitance requirement for this crystal?

This HC-49SMD crystal is specified for a 20pF load capacitance. Use two 20pF capacitors—one from each pad to ground—to achieve the correct oscillation frequency.

Can I use this 14.7456MHz crystal in a microcontroller clock circuit?

Yes. Many microcontrollers support external crystals in this frequency range. The 14.7456MHz frequency is especially useful for serial communication interfaces requiring standard baud rates.

Which soldering method is recommended for mounting this SMD crystal?

Use a standard SMD reflow soldering process with a peak temperature of around 240 °C. Ensure the PCB footprint matches the HC-49SMD pad layout and follow a recommended thermal profile to avoid damage.
