The Ebike MY1016Z2 250W 3300 rpm Geared DC motor is a widely used reduction dc motor for scooters, bikes, and quads. It is also suitable for many DIY projects like Segway, e-cars, and robots like ATV robots, combat robots, etc. because of its durability. It is a mid-range motor that is better than the low-range ones that have a plastic toy gearbox and a Johnson or Mabuchi 550 motor. Many people choose this 250W motor as a base for building their own carts, warbot, Segways, etc. It can support kids up to about 5-7 years old.
If you want to build an E-bike and are not sure what motor to use, you can find everything you need at zbotic. We have the best products and services for your E-bike project.
NOTE: On sticker rated speed 3300 RPM is before gear and 3300 RPM is output speed of the motor
specification-
| Model | MY1016Z2 |
|---|---|
| Rated Current(A) | 2.2 |
| Voltage | 24V |
| Rated Speed | 3300 RPM (speed of motor before geared) 360 RPM (after geared output speed) |
| Operating Power | 250 Watt. |
| Gear Ratio | 9.78:1 |
| Rated Torque (Kg-Cm) | 8.15 |
| Min. Reduction Ratio | 9.78 |
| Gearbox | Yes. |
| Cable Length (Meter) | 0.5 |
| Weight (Kg) | 2.35 |
| Shipping Weight | 2.4 kg |
| Shipping Dimensions | 22 × 15 × 12 cm |
Package Includes :
1 x Ebike MY1016Z2 250W3300 rpm Geared DC motor.
