This is the White variant of the Waveshare 2.42inch OLED Display Module, 128×64 Resolution, SPI / I2C Communication (White) in OLED Display. Available at Original price was: ₹1,886.82.₹1,473.82Current price is: ₹1,473.82. (₹1,249.00 + GST) with free shipping across India.
The Waveshare 2.42-inch OLED Display Module features a sharp 128×64 resolution for clear visuals. With versatile SPI and I2C communication options, it suits diverse applications. The module offers a compact design ideal for projects requiring efficient graphical interfaces.
Features:
- Ultra-narrow bezel, compact size, with onboard voltage translator
- Adopts 4-wire SPI and I2C interfaces, better compatibility, fast data rate
- Comes with online development resources (examples for Raspberry Pi/Raspberry Pi Pico/Arduino/STM32/ESP32/Jetson Nano)
Useful Link:
https://www.waveshare.com/wiki/2.42inch_OLED_Module
Specification:
| Model Type: | OLED Display Module |
|---|---|
| Display Size (Inch): | 2.42 |
| Operating Voltage | 3.3V / 5V |
| Resolution: | 128 × 64 pixel |
| Communication Interface | 4-wire SPI (default) / I2C |
| Display: | 2.42inch OLED Module: white |
| Display Panel | OLED |
| Driver | SSD1309 |
| Module Size | 61.50 × 39.50mm |
Package Includes:
1 x Waveshare 2.42inch OLED Display Module, 128×64 Resolution, SPI / I2C Communication (White)
Sequential Switch: Step Through Outputs Circuit
Understanding the sequential switch is essential for anyone working with electronics in India. This comprehensive guide covers sequential...
Read More →
Seed Starting Heat Mat: Temperature Controller
Table of Contents Why Use a Heat Mat for Seeds? Temperature Requirements for Germination Components for the Build...
Read More →
MOSFET vs BJT: Power Switching Transistor Comparison
MOSFET vs BJT: Power Switching Transistor Comparison If you have ever built a motor driver, LED dimmer, or...
Read More →Technical Specifications
| Brand | WAVESHARE |
|---|---|
| Display Size | 2.42" |
| Interface / Protocol | I2C, SPI |
| Package Quantity | 64 pcs |
| Color | White |
| SKU | AI6652 |
| Weight | 0.036400 kg |
| Availability | In Stock |
Applications & Use Cases
The Waveshare 2.42inch OLED Display Module, 128×64 Resolution, SPI / I2C Communication (White) is a versatile oled display used across a wide range of applications including wearable electronics, IoT sensor readouts, small embedded displays, DIY clocks and meters, and battery-powered gadgets.
Common use cases:
- Displaying temperature/humidity on an Arduino project
- Building a DIY smartwatch
- Adding a status display to a custom PCB
This product is ideal for makers, Arduino/ESP32 developers, and electronics hobbyists.
Technical Tip: OLED displays consume power per-pixel — black pixels use zero power, making them ideal for battery-powered projects with sparse displays.
