This is the Red variant of the Unsoldered TTGO T-Display ESP32 WiFi Bluetooth Module Development Board 1.14 Inch LCD Control Board 4MB CH9102F Chip in IoT Development Boards. Available at ₹1,453.76 (₹1,232.00 + GST) with free shipping across India.
Description:
The Unsoldered TTGO T‑Display ESP32 is a development board built around the ESP32 microcontroller and is tailored for embedded and IoT projects that require both compute capability and a display interface. The integrated 1.14″ TFT LCD (IPS) allows you to present visual feedback (menus, graphs, sensor data, etc.) without needing an external screen.
Because it comes unsoldered, you have the freedom to place it onto custom PCBs, breadboards, or connectors of your choosing. It also includes provisions for a 3.7 V Li‑ion / LiPo battery via JST connector, with onboard battery management. Power and programming are handled over a USB‑C port via an onboard USB‑to‑UART bridge.
This board is well‑suited for wearable devices, portable controllers, dashboards, sensor monitors, and other IoT nodes where both display and wireless interface are needed.
Features
- Onboard 1.14″ IPS TFT display, driven by ST7789 (or compatible) controller
- ESP32 dual-core Xtensa LX6 microcontroller (up to 240 MHz)
- 4 MB QSPI flash memory
- 520 kB SRAM
- USB‑C connector for power, programming, and charging
- USB-to-UART bridge chip: CP2104 or CH9102F (depending on variant)
- Battery support with onboard charging circuitry (via JST connector)
- Rich peripheral support: UART, SPI, I²C, ADC, DAC, PWM, I²S, touch sensor support, IR GPIO
- Low power operation modes (sleep / deep sleep)
- Operating voltage: ~2.7 V to 4.2 V
- Operating temperature: –40 °C to +85 °C
Specifications:
| Parameter | Value |
|---|---|
| Microcontroller | ESP32 (Xtensa LX6 dual core, up to 240 MHz) |
| Flash Memory | 4 MB QSPI |
| SRAM | 520 kB |
| Display | 1.14″ IPS TFT, 135 × 240 resolution |
| USB‑to‑UART | CP2104 or CH9102F (depending on board variant) |
| Operating Voltage | 2.7 V to 4.2 V |
| Max Operating Current | ~ 60–70 mA (active) |
| Sleep / Deep Sleep Current | On the order of tens to hundreds of microamps (varies with configuration) |
| Interfaces / Peripherals | UART, SPI, I²C, ADC, DAC, PWM, I²S, IRGPIO, capacitive touch, etc. |
| Battery Support | JST 2‑pin connector for 3.7 V LiPo / Li‑ion battery; onboard charger |
| USB Connector | USB Type‑C |
| Operating Temperature | –40 °C to +85 °C |
| Board Dimensions | ~ 51.52 × 25.04 × 8.54 mm |
Package Includes:
- 1 x Unsoldered TTGO T-Display ESP32 WiFi Bluetooth Module Development Board 1.14 Inch LCD Control Board 4MB CH9102F Chip
