TJA1050 CAN Controller Bus Driver Interface Module
The TJA1050 CAN Bus Controller Interface Module serves as a bridge between the CAN protocol controller and the physical bus. It enables the controller to transmit and receive differential signals to and from the bus. As Philips’ third-generation high-speed CAN transceiver, following the PCA82C250 and PCA82C251, the TJA1050 offers several key improvements:
– Significantly reduced electromagnetic emissions due to optimal signal matching between CANH and CANL.
– Enhanced performance when a node is unpowered, ensuring better reliability in systems where some nodes may be powered down.
– No standby mode, which simplifies operation and ensures continuous functionality.
These enhancements make the TJA1050 ideal for use in power-down situations or partially powered networks, offering robust performance and efficient signal transmission.
Features
This text describes an onboard TJA1050 CAN controller interface chip with the following features:
– It has common pins for easy connection.
– It uses a 5 V power supply.
– It has a PCB board size of 22 mm x 11.5 mm.
– It is fully compatible with the ISO 11898 standard.
– It supports high speed (up to 1 Mbaud).
– It has very low Electro-Magnetic Emission (EME).
– It has a differential receiver with a wide common-mode range for high Electro-Magnetic Immunity (EMI).
– It does not disturb the bus lines when unpowered.
– It has a Transmit Data (TXD) dominant time-out function.
– It has a silent mode that disables the transmitter.
– It is protected against transients in an automotive environment.
– It is compatible with input levels of 3.3 V and 5 V devices.
– It is thermally protected.
– It is short-circuit proof to the battery and to ground.
Package Includes
1 x TJA1050 CAN Controller Bus Driver Interface Module
TJA1050 CAN Controller Bus Driver Interface Module Overview
The TJA1050 CAN Controller Bus Driver Interface Module is a compact breakout board featuring the Philips TJA1050 high-speed CAN transceiver. It serves as a physical-layer bridge between a microcontroller’s CAN controller and the CAN bus, enabling reliable differential signaling for data rates up to 1 Mbaud.
Key Features of TJA1050 CAN Controller Bus Driver Interface Module
Onboard Philips TJA1050 high-speed CAN transceiver chip
Fully compatible with ISO 11898 standard, supporting up to 1 Mbaud
Compact PCB size (22 mm × 11.5 mm) for space-constrained designs
Built-in status LED on the common pin for real-time bus activity indication
Reduced electromagnetic emissions thanks to optimized CANH/CANL matching
Enhanced unpowered-node performance—ensures bus stability when some nodes are off
Easy connection: 5 V power input, GND, TXD/RXD logic lines and CANH/CANL terminals
Genuine product with fast shipping across India from Zbotic
Applications and Use Cases
Automotive diagnostics and ECU communication testing
Industrial automation networks and PLC integration
Embedded robotics requiring multi-node CAN communication
Data logging systems for engine sensors or environmental monitors
Prototyping CAN-based control in electric vehicles and battery management
Home or building automation modules using a CAN backbone
How to Use TJA1050 CAN Controller Bus Driver Interface Module
To get started, mount the module on your test jig or breadboard, supply 5 V to the VCC pin and connect GND to your controller ground. Link the module’s TXD and RXD pins to your microcontroller’s CAN_TX and CAN_RX lines, then attach CANH and CANL to your bus wiring with proper termination resistors (120 Ω at each end). Power up and observe the onboard LED for bus activity—data can now flow bi-directionally between your CAN controller and the network.
