This is the Green variant of the SW-200D Green Double Ball Rolling Vibration Sensor Switch in Vibration/Tilt Sensor and Modules. Available at Original price was: ₹69.62.₹54.28Current price is: ₹54.28. (₹46.00 + GST) with free shipping across India.
Looking for Sw-200d Sensor? SW-200D Green Double Ball Rolling Vibration Sensor Switch is available at Zbotic with fast shipping across India.
SW-200D is a dual ball type single direction tilt sensitive trigger switch. It is commonly used in automation devices. Hobbyists also use it on robotic chassis. When the device tilts to the conductive terminal (silver pin end – A) by more than 10 degrees, it will be at open circuit “OFF-state”. When its horizontal postion changes, the trigger terminal (gold-pin end B) is below the horizontal tilt angle and more than 10 degrees, it will be at closed circuit “ON-state”.
Specification:
- Type: dual rolling ball
- Material: plastic / metal
- Shape: Round
- Contact Rating: Upto 5V/10mA
- Life span: 10,0000 cycles
- Contact Resistance: 10ohm
- Insulation Resistance: >10M ohm min. at 24VDC
- Li Contact Resistance: 10ohmfe span: 10,0000 cycles
- Capacitance: 5pF
Package Include :
1 X SW-200D Green Double Ball Rolling Vibration Sensor Switch
SW-200D Green Double Ball Rolling Vibration Sensor Switch Overview
The SW-200D Green Double Ball Rolling Vibration Sensor Switch is a compact tilt-activated switch that uses two internal metal balls to detect directional movement. Designed for single-axis vibration and tilt sensing, it’s ideal for robotics, automation panels and DIY motion-detection projects.
Key Features of SW-200D Green Double Ball Rolling Vibration Sensor Switch
- Dual rolling ball design for reliable single-axis tilt detection
- Compact round plastic and metal housing for space-constrained setups
- Low contact resistance (~10 Ω) and capacitance (5 pF) for precise switching
- Contact rating up to 5 V/10 mA and insulation resistance >10 MΩ at 24 VDC
- Long lifespan: up to 100,000 switching cycles
- Fast shipping across India from Zbotic for quick prototyping and production
Applications and Use Cases
- Robotic chassis orientation sensing and anti-tilt protection
- Portable devices for vibration or movement alarms
- Automated machinery tilt-detection switches
- DIY motion-sensing circuits in hobby electronics
- Security sensors for drawer or cabinet tilt monitoring
How to Use SW-200D Green Double Ball Rolling Vibration Sensor Switch
Mount the SW-200D on a stable surface, align the silver (A) and gold (B) pins to match your tilt axis, and wire the common pin to ground and the desired pin (A or B) to an input pin on your microcontroller or circuit. Apply a supply voltage below 5 V and monitor the digital input: it will close when tilted more than 10° toward the gold-pin end and open when tilted toward the silver-pin end beyond 10°.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
What tilt angle does the SW-200D require to switch states?
The SW-200D toggles to an OFF-state when tilted more than 10° toward the silver pin (A) and switches to an ON-state when tilted more than 10° toward the gold pin (B) from horizontal.
Can I use the SW-200D at higher voltages or currents?
No. The sensor is rated up to 5 V and 10 mA. Exceeding these limits can damage the internal contacts. For higher loads, use a suitable driver transistor or relay.
How do I mount and connect the SW-200D in my project?
Secure the round housing to a flat surface using adhesive or a mounting bracket. Solder wires or use a PCB socket to connect the common pin to ground and one of the switch pins to your signal line. Ensure correct orientation for your desired tilt direction.
