This is the Black variant of the Radiomaster TX16S Mark II Max Radio Controller (M2) – ELRS- Black in Drone Transmitter and Receiver. Available at ₹32,197.48 (₹27,286.00 + GST) with free shipping across India.
Looking for Tx16s Controller Radiomaster Black? Radiomaster TX16S Mark II Max Radio Controller (M2) – ELRS- Black is available at Zbotic with fast shipping across India.
Radiomaster TX16S Mark II Max Radio Controller (M2) – ELRS- Black
Tx16s Controller Radiomaster Black – Description:
The Radiomaster TX16S Mark II Max Radio Controller (M2) – ELRS- Black is a feature-rich and versatile radio transmitter designed to meet the needs of experienced RC users and enthusiasts, especially those looking for long-range performance and advanced customization options. It integrates seamlessly with ExpressLRS technology, offering high-performance and low-latency communication.
The controller features a high-resolution color touchscreen display, multiple switch options, customizable controls, and multi-protocol support. With OpenTX firmware support and ergonomic design, it provides comfortable and precise control for a wide range of RC applications, including drones, airplanes, helicopters, cars, and boats.
Features:
- Improved internal circuitry and optimized power supply.
- New charge circuitry with integrated reverse-polarity protection.
- Optimized charge IC now allows up to 2.2A internal USB-C charge current.
- Rear-mounted audio jack provided headphone output.
- V4.0 Gimbal improved centering and temperature stability (Same circuitry as AG01).
- Optional high/low rear grips are included for improved ergonomics.
- Improved S1/S2 knobs with clear center detents.
- Improved LS/RS Sliders with smoother feel and better center detents.
- Redesigned battery cover for improved battery access.
- Retooled body shell with improved fit and finish.
- Trainer socket changed to standard TRS 3.5mm socket.
- Rear DIY Socket added for personalized mods.
- Transmission frequency: 2.400GHz-2.480GHz
- Improved internal plastics for better longevity.
Specifications:
| Item Type: | Controller |
|---|---|
| No. of Channels: | 16 |
| Model Name | TX16S MKII MAX ELRS Carbon/Black |
| Color: | Black |
| Operating Current (A): | 0.4 |
| Operating Voltage (VDC): | 6.6-8.4 |
| Antenna Gain | 2dB |
| Firmware: | EdgeTX |
| Size (Inch): | 4.3 |
| Resolution: | 480 x 272 |
| Length (mm): | 287 |
| Width (mm): | 129 |
| Height (mm): | 184 |
Radiomaster TX16S Mark II Max Radio Controller (M2) – Overview
The Radiomaster TX16S Mark II Max Radio Controller (M2) – ELRS- Black is a high-performance multi-protocol transmitter designed for RC pilots seeking long-range, low-latency control. Equipped with ExpressLRS integration and OpenTX firmware, it delivers precise signal transmission for drones, airplanes, helicopters, and custom RC projects.
Key Features of Radiomaster TX16S Mark II Max Radio Controller (M2) –
- High-resolution color touchscreen display for intuitive menu navigation and rapid settings adjustment
- ExpressLRS (ELRS) support for extended range and ultra-low latency communication
- Multiple six-position switches, knobs and sliders for fully customizable control layouts
- Built-in multi-protocol RF module bay, compatible with ExpressLRS, DSMX, FrSky, FlySky and more
- OpenTX firmware support enabling advanced model setup, telemetry, voice alerts and OTA updates
- Ergonomic design with comfortable grips and balanced weight for hours of fatigue-free flying
- Fast shipping from Zbotic across India
Applications and Use Cases
- FPV racing drones requiring ultra-responsive control and real-time telemetry feedback
- Long-range fixed-wing aircraft flights needing reliable signal performance over kilometers
- RC helicopters with complex collective and cyclic control demands
- Custom-built UAVs for aerial photography, surveying or inspection missions
- Gliders and sailplanes benefiting from precise throttle and flap management
How to Use Radiomaster TX16S Mark II Max Radio Controller (M2) –
Unbox the TX16S Mark II Max, install charged Li-ion cells or connect the USB-C cable, then power on. Enter the touchscreen setup menu, select “Model Setup,” choose ExpressLRS under RF Protocol, and initiate binding while your receiver is in bind mode. Calibrate gimbals, assign switches, save the profile, and you’re ready to start flying.
Why Buy from Zbotic?
- Genuine Products: All items sourced from authorized distributors
- Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
- Free Shipping: Free delivery on qualifying orders
- COD Available: Cash on Delivery, UPI, cards, net banking
- Technical Support: Expert help for setup and troubleshooting
- Easy Returns: Hassle-free replacement for defective products
Frequently Asked Questions
How do I bind the Radiomaster TX16S Mark II Max to an ExpressLRS receiver?
Power on the controller and receiver in bind mode. On the TX16S touchscreen, navigate to Model Setup → Internal RF → ExpressLRS → Bind. Press Bind, wait for the LED on both units to turn solid, then exit the menu to complete binding.
Can I expand to other RF protocols on the TX16S Mark II Max?
Yes. The built-in multi-protocol module bay supports popular RC systems like DSMX, FrSky and FlySky. Install the desired RF module, select the matching protocol in Model Setup under Internal RF, and configure channel mapping as needed.
How do I update the OpenTX firmware on the Radiomaster TX16S Mark II Max?
Download OpenTX Companion on your computer, connect the TX16S via USB-C while holding the trim buttons to enter bootloader mode, select the TX16S Mark II Max profile, choose the firmware version, and click “Write Firmware.” After flashing, restart the radio.
Datasheet:
Package Includes:
- 1 x Radiomaster TX16S Mark II Max Radio Controller (M2) – ELRS- Black
