This is the Green variant of the MAD CO – FS 2004 DYNAMO FPV Drone motor (Green) 3500KV in Drone Motor. Available at ₹3,078.60 (₹2,608.98 + GST) with free shipping across India.
MAD CO – FS 2004 DYNAMO FPV Drone motor (Green) 3500KV
Description:
The FS series of MAD FPV brushless motors is designed for freestyle flying. The development process involved six months of rigorous testing, resulting in refined aesthetics and functionality.
The main difference between the FS and BSC series is the superior quality of the materials used.
Features:
- Designed for FPV racing drones
- Compact and durable design
- Balanced between speed and torque for agile flight
Specification:
| Model Name: | Dynamo FS2004 |
|---|---|
| Shaft Diameter (mm): | 1.5 |
| Color: | Green |
| Motor KV (RPM/V): | 3500 |
| Motor Type: | Brushless Motor |
| Compatible LiPO Batteries: | 4S |
| Framework | 12N14P |
| Max. Efficiency Current (A) | 7–9 |
| Max. Power (W) | 150–200 |
| Maximum Thrust (gm) | 450–600 |
| No-load current (A) | 0.5 |
| No-Load Current (mA) | 500 |
| Outer Diameter (mm): | 24.3 |
Package Includes:
1 x MAD CO – FS 2004 DYNAMO FPV Drone motor (Green) 3500KV
Agricultural Drone Spraying System: Components and Setup
A well-designed agricultural drone spraying system is the heart of any crop protection drone, directly determining spray coverage,...
Read More →
Water Pump Motor Control with Relay & Float Sensor Arduino
Table of ContentsIntroduction: Why Automate Your Water Pump?Components RequiredHow a Float Sensor WorksRelay Module Basics for BeginnersWiring Diagram:...
Read More →
Z-Axis Leadscrew Motor for CNC: Pitch, Nut & Drive Explained
The Z-axis on any CNC machine is arguably the most critical axis to get right. It controls cutting...
Read More →Technical Specifications
| Brand | MAD COMPONENTS |
|---|---|
| KV Rating | 3500KV |
| Color | Green |
| SKU | AI8128 |
| Weight | 0.028 kg |
| Availability | Out of Stock |
Applications & Use Cases
The MAD CO – FS 2004 DYNAMO FPV Drone motor (Green) 3500KV is a versatile drone motor used across a wide range of applications including FPV racing drones, agricultural spray drones, aerial photography platforms, and custom multirotor builds.
Common use cases:
- Replacement motor for crashed or worn-out drone
- Building a custom quadcopter or hexacopter from scratch
- Upgrading to a more efficient motor for longer flight times
This product is ideal for drone builders, FPV pilots, and agricultural drone operators.
Technical Tip: When selecting a drone motor, match the KV rating to your propeller size and battery voltage. Lower KV = larger props + more efficiency; higher KV = smaller props + more speed.
