LPC822M101JDH20J ARM Microcontroller
The LPC822M101JDH20J is a member of NXP’s LPC800 series, featuring an ARM Cortex-M0+ processor. Here’s a detailed description of its features:
Core: Powered by an ARM Cortex-M0+ processor, running at speeds up to 30 MHz. The Cortex-M0+ offers a balance between performance and power efficiency, making it suitable for a wide range of embedded applications.
Memory: The microcontroller includes 16 KB of flash memory for program storage and 4 KB of SRAM for data storage. This memory configuration enables efficient execution of code and manipulation of data in embedded applications.
Peripherals: It features various integrated peripherals, including GPIO (General-Purpose Input/Output) pins for digital interfacing, UART (Universal Asynchronous Receiver/Transmitter) for serial communication, SPI (Serial Peripheral Interface) for interfacing with SPI devices, I2C (Inter-Integrated Circuit) for communication with I2C devices, and ADC (Analog-to-Digital Converter) for analog sensor interfacing.
Security Features: The LPC822M101JDH20J incorporates security features such as a unique device identifier (UID) and a hardware AES (Advanced Encryption Standard) encryption engine to ensure data security.
Power Management: With its low-power Cortex-M0+ core and multiple power modes (including sleep and deep sleep modes), the LPC822M101JDH20J is suitable for battery-powered applications and those requiring energy efficiency.
Package: It is available in a 20-pin HVQFN package, which is compact and suitable for space-constrained applications.
Operating Voltage: The microcontroller operates in the voltage range of 1.8 V to 3.6 V, making it compatible with various power supplies.
Operating Temperature Range: It can operate in temperatures ranging from -40°C to +85°C, making it suitable for use in harsh environmental conditions.
Development Tools: NXP provides a comprehensive set of development tools, including software development kits (SDKs), integrated development environments (IDEs), and debugging tools, to facilitate rapid prototyping and software development for the LPC822M101JDH20J microcontroller.
Note:
- For more technical details, go through the datasheet in the attachments.
- Image may vary from actual product in terms of brand and value printed.
Specification:
| Specification | Value |
|---|---|
| Core | ARM Cortex-M0+ |
| Maximum Frequency | Up to 30 MHz |
| Flash Memory | 16 KB |
| SRAM | 4 KB |
| GPIO | Up to 18 pins |
| UART | Supported |
| SPI | Supported |
| I2C | Supported |
| ADC | Supported |
| Security Features | Unique device identifier, AES encryption |
| Power Management | Low power consumption, multiple power modes |
| Package | 20-pin HVQFN |
| Operating Voltage | 1.8 V to 3.6 V |
| Operating Temperature Range | -40°C to +85°C |
| Development Tools | NXP’s SDKs, IDEs, debugging tools |
Packages Includes:
1 x LPC822M101JDH20J ARM Microcontroller
Datasheet:
LPC822M101JDH20J ARM Microcontroller Overview
The LPC822M101JDH20J is an ARM Cortex-M0+ microcontroller from NXP’s LPC800 series, designed for compact embedded applications requiring efficient processing. With its 30 MHz core and integrated flash and SRAM, it serves as a versatile controller for sensor interfaces, simple control loops, and prototypes.
Key Features of LPC822M101JDH20J ARM Microcontroller
- ARM Cortex-M0+ Core: 32-bit processor running up to 30 MHz for balanced performance and power efficiency.
- Integrated Memory: 16 KB of onboard flash memory and 4 KB of SRAM for code and data.
- Compact Footprint: Small package ideal for space-constrained PCBs in consumer and industrial devices.
- Low-Power Operation: Efficient energy usage suited for battery-powered and always-on applications.
- Development Support: Compatible with NXP MCUXpresso IDE and standard SWD programming/debugging tools.
- Fast Shipping from Zbotic: 100% genuine product with speedy delivery across India.
