GEPRC-CL20 Frame Drone Frame and Accessories

GEPRC-CL20 Frame:

The GEPRC CL20 is a lightweight 2-inch pusher frame ideal for tight spaces and stable cinematic flying. Supporting O3 VTX and various naked cameras, it features a redesigned anti-jello camera gimbal for smoother footage. Its soft damping connections and EVA impact rings ensure vibration control and structural durability. With versatile mounting options and a compact footprint, the CL20 delivers a confident and powerful flight experience for micro cinewhoop enthusiasts.

Features:

1. Anti-shake camera gimbal with soft damping to reduce jello.
2. Compact 2-inch pusher frame for flying in narrow spaces.
3. Supports a wide range of cameras including Naked GP8/9/10/11, DJI Action2, Insta360 Go2.
4. EVA damping rings and injection-molded prop guards for enhanced impact protection.
5. 7075 aluminum columns for a rigid yet lightweight structure.
6. FC and VTX mount compatibility with 25.5×25.5mm and 20x20mm hole patterns.

Specification

Package Includes:

Plates:

1 × Main Plate (2.5mm)

1 × Bottom Plate (1.5mm)

1 × Camera Gimbal Plate (2.0mm)

1 × Motor Plate Gasket (2.0mm)

Screw Package:

Various M2 & M1.6 Screws, Nuts, Nylon Nuts & Columns (detailed as per spec)

7075 Aluminum & Bright-Edge Aluminum Columns

Camera Gimbal Shock Absorbing Rings & Dampers

BEC Silicone Gaskets

3D Printed Parts:

VTX Antenna Mount (Big & Small Hole)

Receiver Mounts (x2)

TBS Antenna Mount

Camera Mount (1 Hole & 2 Holes)

Injection Molded Parts:

4 × Propeller Guards

Other Accessories:

1 × Naked Camera GP8 Base

1 × 4S Naked GP Power Cable

Battery Anti-Slip Pads, Damping Pads, EVA Rings

Receiver Antenna Tubes (x2)

Battery Ties (x2)

1 × L-shaped Screwdriver

3M Tape (x2)

1 × Keychain

GEPRC-CL20 Frame Overview

The GEPRC-CL20 Frame is a lightweight, compact 2-inch cinewhoop pusher frame designed for micro FPV drones. Crafted for tight indoor and outdoor environments, it delivers smooth cinematic footage with its anti-vibration camera gimbal and robust EVA damping system.

Key Features of GEPRC-CL20 Frame

• Anti-shake camera gimbal with soft damping to minimize jello in footage
• Compact 2-inch pusher design for navigating narrow corridors and confined spaces
• Supports DJI O3 VTX, Naked GP8/9/10/11 and Insta360 Go2 cameras
• 7075 aluminum hardware paired with EVA damping rings for durability and vibration control
• Injection-molded prop guards and EVA impact rings for enhanced crash protection
• Fast shipping from Zbotic ensures you get flying sooner

Applications and Use Cases

• Indoor cinematic shoots in tight hallways, stairwells or industrial interiors
• Close-quarter FPV racing through obstacles or urban playgrounds
• Freestyle drone maneuvers in compact studios or living rooms
• Aerial B-roll for real estate walkthroughs and architectural reveals
• Action sports coverage in skate parks or BMX tracks with minimal clearance
• Event highlights where discreet, low-noise flight is essential

How to Use GEPRC-CL20 Frame

Begin by mounting your 20 mm brushless motors to the frame’s reinforced arms, then fit the EVA damping rings around the central cage. Attach your chosen camera—DJI O3, GP-series or Insta360 Go2—into the anti-jello gimbal, secure with the soft-damping connectors, and install prop guards. Finally, wire your flight controller and VTX, perform a vibration test, and tune your PID settings for optimal stability before taking to the skies.

Why Buy from Zbotic?

• Genuine Products: All items sourced from authorized distributors
• Fast Shipping: Orders ship within 24 hours with tracking (non backordered products)
• Free Shipping: Free delivery on qualifying orders
• COD Available: Cash on Delivery, UPI, cards, net banking
• Technical Support: Expert help for setup and troubleshooting
• Easy Returns: Hassle-free replacement for defective products

Frequently Asked Questions

Which cameras are compatible with the GEPRC-CL20 frame?

The CL20 frame supports DJI O3 VTX modules and a range of naked action cameras, including GP8, GP9, GP10, GP11 and Insta360 Go2, thanks to its adjustable mounting plates and anti-vibration gimbal.

How does the EVA damping ring improve flight performance?

EVA damping rings isolate the camera and central chassis from high-frequency motor vibrations, reducing jello in your footage and preserving structural integrity during impacts.

Can I install injection-molded prop guards on this frame?

Yes, the GEPRC-CL20 includes integrated slots for injection-molded prop guards, allowing quick installation and replacement to protect both propellers and surroundings during indoor flights.
