The EGS002 is a driver board designed specifically for single-phase sinusoidal inverters, featuring the EG8010 ASIC as its control chip and the IR2110S as its driver chip. This board incorporates voltage, current, and temperature protection functions, along with LED indicators and fan control. Configuration options include 50/60Hz AC output, soft start mode, and adjustable dead time. The EGS002, an upgrade of the EGS001, maintains compatibility with the original interfaces of the EGS001 and adds cross-conduction prevention logic to improve anti-interference capabilities, as well as an LCD display interface to utilize the chip’s built-in display feature.
The EG8010 is a digital, pure sine wave inverter ASIC with a comprehensive set of functions, including built-in dead time control. It is suitable for use in DC-DC-AC two-stage power converter systems or DC-AC single-stage low power frequency transformer systems intended for boosting purposes. With an external 12MHz crystal oscillator, the EG8010 can generate a 50/60Hz pure sine wave with high precision, minimal harmonic distortion, and low distortion. It is a CMOS IC that integrates an SPWM sinusoid generator, dead-time control circuit, range divider, soft start circuit, circuit protection, RS232 serial communication, a 12832 serial LCD unit, and more.
Applications:
Single-phase pure sine wave inverter
PV Inverter
Wind power inverter
Uninterruptible Power Supply UPS System
Digital generator system
IF power
Single-phase motor speed controller
Single-phase inverter
Sine wave dimmer
Sine wave regulator
Sine wave generator
Package Includes:
1 x EGS002 EG8010 IR2113 DC-AC SPWM Pure Sine Wave Inverter Board.
The EGS002 EG8010 + IR2113 DC-AC SPWM Pure Sine Wave Inverter Module is a versatile signal generator module & oscilloscopes used across a wide range of applications including electronics projects, DIY builds, prototyping, and educational experiments.
Common use cases:
Integrating into a custom electronics project
Learning and experimenting with circuits
Replacing or upgrading components in existing setups
This product is ideal for electronics enthusiasts, engineers, and students.
Technical Tip: Always verify voltage and current requirements before connecting to your circuit. Check datasheets for detailed specifications and pin configurations.
